2 Ton Mezzanine Industrial Hydraulic Lift Multi Level Warehouse Goods Handling
2 Ton Mezzanine Industrial Hydraulic Lift Multi Level Warehouse Goods Handling
Specifications
Brand Name :
HAOXIANG BRAND
Model Number :
DSL2-3
Certification :
CS/ISO
Place of Origin :
GUANGDONG,CHINA
MOQ :
1 unit
Price :
USD1600- USD6800 / UNIT
Payment Terms :
T/T
Supply Ability :
2000 units per year
Delivery Time :
7-15 working days
Packaging Details :
Naked packaging
Door Opening Size :
Customized
Platform Size :
2.5m*2.5m
Capacity :
2000kg
Control System :
PLC control
Lifting Height :
3m
Material :
Steel
Product Name :
Hydraulic Guide Rail Lift
Country of Origin :
Made in China
Control Mode :
Hydraulic
Rated Load :
Up to 30 tons,Customizable
Description

2 Ton Hydraulic Guide Rail Lift with Safety Interlocks, 3m Travel Height, for Multi-Level Warehouse Cargo Handling

Durability is at the core of the Hydraulic Guide Rail Lift. It is coated with industrial-grade powder paint to resist corrosion and environmental damage. The platform uses thickened checker plate steel that provides anti-slip performance and strong load-bearing capacity. With its robust design, the lift requires minimal maintenance and offers long-term performance under heavy-duty conditions.

Technical Parameter
Specifications, sizes and colors can be customized according to customer requirements
Model Rated load (kg) Lifting stroke (mm) Lowering height (mm) Table size (mm) Lifting time Motor power (kw)
DSL1-3 1000 3000 100 2000×1800 6m/min 3
DSL1-12 1000 12000 100 2500×2000 6m/min 3
DSL2-4 2000 4000 150 2000×1800 6m/min 4
DSL2-10 2000 10000 200 3000×3500 6m/min 4
DSL3-5 3000 5000 150 3000×1800 6m/min 5.5
DSL3-8 3000 8000 150 2000×1700 6m/min 5.5
DSL4-5 4000 5000 250 3000×4000 6m/min 7.5
DSL4-10 4000 10000 150 5000×3000 6m/min 7.5
DSL5-6 5000 6000 400 5800×3000 6m/min 11
DSL10-15 10000 15000 400 7000×5000 6m/min 18.5
DSL15-9 15000 9000 800 8000×4000 6m/min 30
DSL15-10 15000 10000 800 9000×4500 6m/min 30
