160T Hydraulic Waste Paper Baler Adjustable Bale Size and PLC Automatic Control
160T Hydraulic Waste Paper Baler Adjustable Bale Size and PLC Automatic Control
Specifications
Model Number :
FW-160T
Pressure :
160T
Supply Ability :
20set monthly
Delivery Time :
15-20working days
Price :
negotiation
Packaging Details :
wooden box
Payment Terms :
T/T
Place of Origin :
China
MOQ :
1
Brand Name :
huawei
Bale Size :
W1100*H1250*( L can be adjustable）
Description

Hydraulic Waste Paper Baler with 160T Pressure, Adjustable Bale Size, and PLC Automatic Control

Hydraulic Waste Paper Baler
The Hydraulic Waste Paper Baler is primarily designed for packing loose materials in large waste paper recycling operations. It efficiently processes materials such as waste paper edges, cardboard boxes, carton edges, waste books, magazines, straw, and other similar materials.
Technical Specifications
Specification Value
Main Oil Cylinder Pressure 250
Pressure 160T
Hydraulic System Operating Pressure 20 MPA
Feed Opening Size 1080 * 2000 mm
Bale Size W1100 * H1250 * (L adjustable)
Bale Density ≥450 KG/m³
Baler Line Wire tie 2.6/3mm 4 Line
Power System High and low pressure combination hydraulic system
Motor Power 50.5 kW
Oil Pump Model VQ45
Pressure 20 Mpa
String Material 5Wsicv
Design System Pressure 25 Mpa
Power Source Specification 3PH 380V
Throughput 5-8 Tons/hour
Control System PLC special probe automatic control system with manual button control operating system
Hydraulic Oil Type 46# Anti-wear hydraulic oil
Cooling System Water-cooling
Machine Weight 15 T
Machine Overall Dimension (L*W*H) 9000 * 4200 * 3000 mm
Bundling Method Automatic bundling
Hold Tight Control Hydraulic automatic hold according to system pressing requirements (PLC automatic control) pressing density
Key Features
  • High-pressure hydraulic system for efficient compression
  • PLC automatic control system with manual override
  • Automatic bundling with wire tie system
  • Water-cooling system for optimal performance
  • Adjustable bale length for flexible operation
  • High throughput capacity of 5-8 tons per hour
