High Compression Ratio Hydraulic Baler Machine with Multi layered Safety Protection 12T
High Compression Ratio Hydraulic Baler Machine with Multi layered Safety Protection 12T
Specifications
Model Number :
huawei30t
Machine Weight :
12T
Payment Terms :
T/T
Supply Ability :
30 set monthly
MOQ :
1
Delivery Time :
20 working days
Safety Protection :
Jerk button
Packaging Details :
wooden
Price :
negotiation
Compression Ratio :
High
Certification :
negotiation
Pression Block Weight :
150-1200kg
Place of Origin :
china
Construction Material :
Thick steel plate
Brand Name :
HUAWEI
Machine Dimension :
8500mm*4100mm*2600mm
Description

High Compression Ratio Hydraulic Baler Machine with Multi-layered Safety Protection and Thick Steel Plate Construction

  • Thick steel plate construction ensures resistance to heavy loads without deformation;
  • Multiple safety features provide greater operational peace of mind;
  • High compression ratio significantly reduces logistics costs;
  • Vertical configuration saves space, while horizontal configuration enables high production capacity;
  • Side-discharge packaging reduces manual handling workload;
  • Loose-material pressure retention function suppresses material rebound;
  • Supports customized voltage specifications for overseas markets, enabling global export capabilities.

Why does packed sponge or cotton material exhibit rebound?

Since sponge and cotton have high rebound coefficients, it is essential to select a specialized machine for bulk materials equipped with a pressure-holding delay function; after pressing, maintain the pressure for several seconds before opening the door to minimize rebound.

Is equipment transported as a complete unit or as separate components?

For vertical machines, they are generally shipped as complete units; upon arrival, they can be placed on-site and connected to the power supply directly; for large horizontal machines where the overall dimensions exceed the permitted limits, the components will be shipped separately, accompanied by assembly drawings.

In low-temperature winter environments, will the hydraulic system perform poorly?

For regions with low temperatures, it is recommended to replace the hydraulic oil with a low-temperature grade; a hydraulic oil heater can also be optionally installed to ensure normal operation during winter in northern regions or overseas countries at high latitudes.

Pressure

25Mpa

string Material

5Wsicv

Design system pressure

25Mpa

power source specification

3PH380V

Throughput

10-18 Tons/hour

Control system

PLC special probe automatic control system manual button control operating system

Hydraulic oil type

46# Anti-wear hydraulicoil
