Carbon Steel Link Clamp Cylinder , Pneumatic Lever Clamp Long Service Life
Carbon Steel Link Clamp Cylinder , Pneumatic Lever Clamp Long Service Life
Specifications
Brand Name :
Jiayan
Model Number :
CALC
Certification :
ISO9001:2008
Place of Origin :
Dongguan china
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
300 sets per week
Delivery Time :
7 days
Packaging Details :
inner packing: poly bag ; outside packing: carton box
Material :
45 # steel
Max. operating pressure :
7 kgf/cm2
Min. operating pressure :
3 kgf/cm2
Description

Pneumatic Lever Clamp Aluminum Alloy Cylinder Body Long Service Life Wear-resistance Surface Carbon Steel Material

FEATURES


1.Adpot Standardized fixture clamp in this series of product, and fitted with lever type holding structure. 2.Piston push out for clamping. Main spare parts of this product be installed outside of the body for convenient maintenance.
3.The material of the body is aluminum alloy. The surface of internal is smooth, and has a long service life. Clamping spare parts material is carbon steel which used for mechanical configuration, firm and wear-resistance.
All models of this series equipped with magnetic induction are available.
Max. operating pressure: 7 kgf/cm2
Min. operating pressure: 3 kgf/cm2
Double acting

NOTE
The acting speed of clamping-unclamping should be slowed down.
