Specifications
Brand Name :
Jiayan
Model Number :
CLKA
Certification :
ISO9001:2008
Place of Origin :
Dongguan China
MOQ :
1 set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
400 sets per week
Delivery Time :
7 days
Packaging Details :
inner poly bag and outer carton box
Material :
Carbon Steel
Max. operating pressure :
70 kgf/cm2
Min. operating pressure :
10 kgf/cm2
Max Clamping Force :
3094kgs
Work Temperature :
-10~+70°C
Max Stroke :
49mm
Warranty :
1 year ( change new for free)
Description

Hydraulic Link Clamp Cylinder Work Fixture Lever Clamp Strong Structure Cylinder Body Dust-proof Design

FEATURES:

Most optimal design to increase the clamping force over traditional clamp cylinder.

Integrated structure to make cylinder body more stronger

Adopt dust-proof design to guarantee high leakproofness

Upper flange to save more mounting space

Max. operating pressure: 70 kgf/cm2

Min. operating pressure:10 kgf/cm2

NOTE:

A flow control valve is recommended

Customized products are available,

welcome to contact us.

ORDER CODE

CLKA – 32 C L

CLKA

Series

CLKA

32

Dia of cylinder body 36: 40:48:48 ;055; 65:;75:;90:105
C Piping Type

Blank: line type

G: Manifold type

C: manifold with flow type

L

Clamping Arm direction

Blank: standard

L:Left

R:Right
