Modular Pressure Reducing Valves BRV Series BRV-02G BRV-02T Hydraulic Check Valves
Modular Pressure Reducing Valves BRV Series BRV-02G BRV-02T Hydraulic Check Valves
Specifications
Brand Name :
Seric
Model Number :
MRV Series
Certification :
CE, ISO
Place of Origin :
Guangzhou, China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T,L/C,Western Union
Supply Ability :
5000
Delivery Time :
1-15 days
Packaging Details :
Carton Box/Wooden Case
After Warranty Service :
Online Support
OEM :
Accept
Condition :
100% Brand-new
Quality :
High-Quality
Application :
Industrial Machinery
Selling Units :
Single item
Description

Pressure Reducing and Check Valves Modular Valve BRV Series BRV-02G BRV-02T

Features

Compared with traditional hydraulic valves, the biggest feature of modular control valves is that they can achieve system installation without the need for piping, thus reducing system leakage, vibration, and noise.

Compared to traditional pipeline connections, modular control valves do not require special installation skills and are very convenient for changing the functionality of hydraulic systems. Due to the absence of piping, the overall reliability of the system is enhanced, and it is easy for daily inspection and maintenance.

It is widely applicable to various industrial hydraulic systems, such as injection molding machine hydraulic systems, CNC machine tool hydraulic systems, metallurgical equipment hydraulic systems, etc.

Symbol

Modular Pressure Reducing Valves BRV Series BRV-02G BRV-02T Hydraulic Check Valves

Specifications

Model Max. operating pressure
(kgf/cm²)		 Pressure adj. range
(kgf/cm²)		 Max. flow
(L/min)		 Weight
(kg)
BRV-02G-※ 250 0: 0 - 35
1: 7 - 70
2: 7 - 140
3: 7 - 210		 35 1.3
BRV-02T-※ 35 1.3

Model Number Designation

BRV 02 G 3 A L
SERIES NUMBER VALVE SIZE MOUNTING PRESSURE ADJUSTING RANGE DIRECTION OF KNOB KNOB TYPE
BRV 02: 1/4" G: Sub-plate mounting

T: Threaded connections		 0: 0-35 kgf/cm²
1: 7-70 kgf/cm²
2: 7-140 kgf/cm²
3: 7-210 kgf/cm² 		A: A port side
B: B port side (standard type)		 K: Haft turning knob bolt rod adjust
L: Inner hexangular bolt rod adjust
