HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building
HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building
HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building
HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building
HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building
HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building
Specifications
Brand Name :
AVITT ZHONGFAN OR OTHERS
Model Number :
HGY14 Concrete place boom
Certification :
CE, ISO, GOST, CU-TR
Place of Origin :
China
MOQ :
1 set
Price :
$15900-22900 per set
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
40 sets per month
Delivery Time :
30 days after receiving the deposit or origin LC
Packaging Details :
Naked packing, 1*20'GP containers per set HGY14 Concrete placing boom
High pressure flexible concrete hose length :
3000 mm
Product Category :
placing boom
Power supply :
380V/50Hz Or According To Client's Requirements
Remote control :
Wired remote control
Working pressure of hydraulic system :
20mpa
Rotation Scope :
360
Support :
Outrigger (4 legs)
Type :
Fixed And Mobile Type
Description

HGY14-3 Concrete Placer Boom 13.5m Light Load by Tower Cranes on Top Building

Performance parameters

Мах. boom length - 13.5 m;

Concrete pipe line (steel, DN125 mm), outer diameter of the and fitting on pipes - 148 mm;

The High pressure flexible concrete hose with two and fitting (3000 mm) must be included in the delivery;

Support - outrigger (4 legs);

Remote control - wired remote control.

Specification

Mobile Hydraulic Concrete Placing Boom
Project name HGY14 HGY15 HGY17 HGY19 HGY21 HGY23
Max. working radius 13.5m 15m 17m 19m 21m 23m
Tilt working range 0°~84° 0°~89° 0°~84° 0°~84° 0°~84° -4°~90°
Slewing working range Full Rotary
Motor power of hydraulic washing system 4kw 4kw 5.5kw 7.5kw 22kw 22kw
Working pressure of hydraulic system 20mpa 20mpa 20mpa 20mpa 32mpa 32mpa
Slewing speed 0.46r/min 0.2-0.3/min 0.2-0.3/min 0.2-0.3/min 0.2-0.3/min 0.2-0.3/min
Concrete pipe specification ∅125*4
Length of hose at arm end 3m
Outrigger span 4000*4000mm 4231*4231mm 5167*5167mm
Overall size of the machine 8900*4000*2585 6000*5000*4000 6670*5730*4510 6500*4800*4600*5312 6839*5089
*5060*5800
Slewing angle 360° 360° 360° 360° 360° 360°
Weight (self-weight/counterweight T) 2.7/4.3 3.23/5.43 5/7.2 5.3/7.5 7.7/9.9 8/10.2
