600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
600W 220-240V 50/60HZ EC Condenser Fan Motor for Air Conditioner with 925RPM Speed
Specifications
Model Number :
TZS-600-10A2-NLR
Brand Name :
trusTec
Place of Origin :
Jiangsu, China
MOQ :
200
Price :
$228.70-230.10
Continuous Current :
5.25A
Efficiency :
Ie 3
Speed :
925RPM
Frame Size :
143mm
Motor Mounting :
foot mount
Rated Power :
220-240W
Rated Voltage :
220-240V
Motor Type :
Condenser Fan Motor
Enclosure Type :
TEAO
Phase :
Single Phase
Shaft Diameter :
12.7mm
Shaft Length :
98.5mm
Max Ambient Temperature :
40℃
Control Mode :
PWM
Poles :
10P
Description
Features and Specifications
Product
Electronically Commutated Motor
Motor Type
Condenser Fan Motor
Enclosure Type
TEAO(Totally Enclosed Air Over)
Thermal Overload
Equipped With An Automatic Thermal Overload
Phase
Single Phase
Mounting
Stud Mounting All Angel
Bearings
Ball Bearing
Mounting Orientation
All Angle
Supply Voltage
220-240V
Supply Frequency
50/60HZ
Current
5.25A
Output Power
220-240W
Rated Speed
925RPM
Frame Size
5.6" / 143mm
Shaft Diameter
0.5" / 12.7mm
Shaft Length
3.87"/98.5mm
Flat Length
3.54"/90mm
Motor Shell Length
5.47"/139mm
Lead Length
19.69"/500mm
Max. Ambient Temperature
40℃/104℉
Control Mode
PWM
Poles
10P
Rotation
CW-LE
Insulation Class
Class B
