Specifications
Series :
micro load cell HX711
Features :
1KG-50KG
Mounting Type :
screw installation
Description :
hx711 load cell, SC133
Model Number :
SC133
Type :
Load Cell
Place of Origin :
Guangdong, China
Brand Name :
SNC
Use :
vending machine load cell
Theory :
strain gauge load cell
Output :
1mv/v
Model :
SC133
Capacity :
1Kg,2kg,3kg,5kg,10kg,2Okg,50kg
Material :
aluminum alloy
Accuracy class :
0.05%
rated output :
1.0±0.15mV/V
Size :
80x12.7x12.7mm
Accessory :
HX711
IP grade :
IP65
Connector :
JST or other crimp and housing support
application :
small scale, micro force/ weight measurement
MOQ :
10 pieces
Price :
$4/pieces 10-49 pieces
Description

Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG + HX711 Weighing Sensors Ad Module

Product Description

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/VHX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/VHX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

Parameters

Application kitchen scale, pricing scale, small weighing scale, force test equipment
Capacity 1kg, 2kg 3kg 5kg 100kg 20kg 30kg 50kg
Comprehensive Error 0.05
Output sensitivity 1.0±0.1mV/V
Nonlinearity 0.05% F.S.
Repeatability 0.05% F.S.
Hysteresis 0.05% F.S.
Creep 0.05 (3min) % F.S.
Zero balance 0.05 (1min) % F.S.
Temperature effect on zero 0.2 % F.S./10℃
Temp. effect on span ≤0.15 F.S./10℃
Zero output ±0.1 MV/V
Input resistance 1000±50 ohm
Output resistance 1000±50 ohm
insulation resistance ≥2000 MΩ
Recommended excitation voltage 5-10V
Ultimate overload 150%F.S.
Load cell material Aluminum alloy
Wiring Red- input+, black- Input-. Green- Output+, White- output -

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

Load cell Accessorie

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

Related Products

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

Packaging & Shipping

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

Company Information

Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.

Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/VHX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

Why Choose Us

HX711 Digital Load Cell Weight Sensor 1KG 5KG 10KG 20KG hx711 load cell Weighing Sensors Ad Module rated output 1.0±0.15mV/V

FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
