RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
RadioMaster TX16S Mark II V4.0 Hall Gimbal 4-IN-1 /ELRS Multi-protocol Radio Controller
Specifications
Material :
Aluminum, PVC
type :
Drone remote control
Type: :
Remote controller
Model Number :
TX16S
Weight: :
750g (without battery)
orking current: :
400mA
Brand Name :
2, Radiomaster
Antenna gain: :
2db (transmit power adjustable)
MOQ :
1 bag
Transmission frequency: :
2.400GHz-2.480GHz
Price :
$146-270 / bag
private mold :
No
compatible brand :
DJI
Place of Origin :
Zhejiang, China, China
Description
Product Description
Product Description

RadioMaster TX16S MKII V4.0 16CH 2.4G Hall Gimbals Transmitter Remote Controller 4in1 /ELRS Multi-protocol Support EDGETX OPENTX

SPECS
Notes:
4in1 (standard) Version supports all MPM protocols
ELRS (standard) is pre-installed witn ExpressLRS ISM FW (Max power is hardware dependnant)
4in1 LBT Version (Europe)is limited to LBT compliant protocols FrSKY X/X2 LBT, HoTT LBT and DSMX
ELRS LBT (Europe) Version is pre-installed with ExpressLRS CE EU domain LBT FW (Limited to 100mw power
output)
Size:287x129x184mm
Weight: 750g (without battery)
Transmission frequency: 2.400GHz-2.480GHzTransmitter module:
Option 1: Internal 4-in-1 multi-protocol module(CC2500 CYRF6936 A7105 NRF2401)
Option 2: lnternal ELRS(SX1280)Transmitting power:
lnternal 4-in-1 multi-protocol module : Max 100mw(protocol dependent)
lnternal ELRS : Max. 250mw(transmitting power is adjustable)
Antenna gain: 2db (transmit power adjustable)working current: 400mA
Working voltage:6.6-8.4v DC
Remote control distance:> 2km @ 22dbmRadio firmware: EdgeTX
Module Firmware: Multiprotocol- Module(4IN1)-
OR- ExpressLRS(ELRS)
Channels: Up to 16 channels (depending on the receiver)Display: 4.3-inch TFT full-colour touch display with a
resolution of 480* 272
Gimbal: Option 1: V4.0 Hall sensor with Aluminium fascia,
Option 2:AG01 CNC Hall sensor
Module Bay: JR compatible module bay
Upgrade method: Supports USB-C online / SD card offline upgrade
IMPROVEMENTS
-lmproved internal circuity and optimized power supply.
- New charge circuitry with integrated reverse-polarity protection.
* Optimized charge IC, better balancing and uSB-C charge current management.· Rear mounted audio jack provides headphone output.
* V4.0 Gimbal improved centring and temperature stability (Same circuitry as AG01)- Optional high/low rear grips included for
improved ergonomics.

-lmproved S1/S2 knobs with clear centre-detents.
-lmproved LS/RS Sliders with smoother feel and better centre-detents.- Redesigned battery cover for improved battery access.
- Retooled body shell with improved fit and finish.
* Trainer socket changed to standard TRS 3.5mm socket.- Rear DIY Socket added for personalised mods.

- lmproved internal plastics for better longevity.·Available ELRS and 4in1 versions.
MAX units feature carbon look face plates and CNC finishing components and buttons.

We have a full range of DJI agricultural drone accessories at extremely cheap wholesale prices Consultations are very welcome.
