Specifications
Brand Name :
HOTHMI
Model Number :
TFT-H080D14XGIJDKG40
Place of Origin :
dongguan,China
MOQ :
2
Payment Terms :
L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability :
99999
Delivery Time :
25 days
Display content :
1024x768 Px
Dimensions (mm) :
192.2x160.1x7.8
Field of view window size :
IPS(U80/D80/L80/R80)
Backlight brightness :
1000cd/m2
Interface :
LVDS
Operating Temperature: :
-30°C to 80°C
Description

TFT-H080D14XGIJDKG40 | 8.0-inch TFT LCD Display with LVDS Interface | 8-inch IPS Display with Protective Cover

  1. Superior Visual Performance: Utilizes a high-brightness backlight and LVDS interface, ensuring vivid, clear, and stable images without flickering, even under direct sunlight or bright ambient light.

  2. Enhanced Durability & Protection: Integrated robust cover glass provides effective defense against scratches, impacts, dust, and moisture, significantly improving reliability and operational lifespan in demanding environments.

  3. Professional Application Assurance: Designed specifically for applications requiring high performance and reliability, such as industrial instrumentation, medical equipment, and outdoor kiosks, aiming to reduce the total cost of ownership.

Product Positioning: An industrial-grade 8-inch display solution that combines excellent visual performance with a rugged construction.

ITEM PARAMETER DESCRIPTION UNIT
TFT series TFT-H080D14XGIJDKG40
Diagonal size 8.0” Inch
Resolution 1024x768 Dot
Dimensions 192.2x160.1x7.8 mm
Active area (AA) 162.048x121.536 mm
LCD type 8.0” TFT Module mm
Display viewing angle Full View
Aspect ratio 3:2
Backlight type LED white
TFT driver IC -
Brightness 1000cd/m2 cd/m2
Operating temperature -30~80℃ ℃
Storage temperature -30~80℃

℃
