Specifications
Brand Name :
HOTHMI
Model Number :
TFT-H101A19HDINV5N40
Place of Origin :
dongguan,China
MOQ :
2
Payment Terms :
L/C, D/A, T/T, D/P, Western Union, MoneyGram
Supply Ability :
99999
Delivery Time :
25 days
Display content :
800x1280 Px
Dimensions (mm) :
142.9x228.5x2.67
Field of view window size :
IPS(U80/D80/L80/R80)
Backlight brightness :
500cd/m2
Interface :
LVDS
Operating Temperature: :
-20~70℃
Driver IC :
NV3051F
Description

TFT-H101A19HDINV5N40 | 10.1-inch TFT LCD Display with LVDS Interface | 800x1280 HD IPS Ultra-thin TFT Display

Introducing our premium 10.1-inch TFT LCD Display, engineered to deliver exceptional clarity and performance for demanding applications. This high-definition screen boasts an 800x1280 resolution with an IPS panel, ensuring vibrant colors and sharp details from every angle. Whether integrated into sophisticated instrumentation or cutting-edge portable electronic devices, this 10.1-inch TFT LCD Display provides a visual output that is both brilliant and reliable.

Durability meets ultra-thin design in this versatile module. With a slim profile and a compact outline, it is perfectly suited for space-constrained projects without compromising on a generous active viewing area. The robust 10.1-inch TFT LCD Display is built to last, featuring an anti-static ESD rating of 8KV and an operating temperature range of -20~70℃, guaranteeing stable performance in various environments.

At the heart of its connectivity is the LVDS interface, driven by the NV3051F chip, which ensures a stable, high-speed signal transmission and pristine image quality. A high brightness of 500 cd/m² makes this display easily readable even under bright lighting conditions. For a powerful combination of HD visuals, ruggedness, and energy efficiency (3.3V power supply), choose this advanced 10.1-inch TFT LCD Display as the core of your next innovation.

ITEM PARAMETER DESCRIPTION UNIT
TFT series TFT-H101A19HDINV5N40
Diagonal size 10.1” Inch
Resolution 800x1280 Dot
Dimensions 142.9x228.5x2.67 mm
Active area (AA) 135.36x216.576 mm
LCD type 10.1” TFT Module mm
Display viewing angle Full View
Aspect ratio 2:3
Backlight type LED white
TFT driver IC NV3051F
Brightness 500cd/m2 cd/m2
Operating temperature -20~70℃ ℃
Storage temperature -30~80℃ ℃
