Specifications
Brand Name :
MENSION
Model Number :
MS-NC130-I
Certification :
CE RoHS
Place of Origin :
CN
MOQ :
1 Set
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Sets Per Month
Delivery Time :
2 - 7 Working Days
Packaging Details :
One Plywood For One Set
Price :
Contact Us
Crimping Range :
14 - 87mm
Hose Size :
1/4 - 2.5inch
Die Sets :
13
Color :
Blue
Max. Opening :
31mm
Crimping Force :
650T
Product Name :
NC130-I Hose Pressing Machine
Application :
Workshop
System Pressure :
31.5Mpa
Power :
3.75KW
Size :
650*550*1360mm
Weight :
310Kg
Description
Hydraulic Pipe Pressing Machine Price Finn Power P32 Manual Water Hose Crimping Tool
FAMOUS HOSE PRESSING MACHINE MS-NC130-I

DESCRIPTION

MS-NC130-I hose crimping machine is suitable for high pressure hydraulic rubber hose crimping up to 2.5 inch. It features substantial crimping force and compact structure with a stable performance system.

ADVANTAGES
  • Famous spare parts, easy to source from local markets
  • Low maintenance cost
  • Quick-change die sets for high efficiency
  • Substantial force with low noise levels
TECHNICAL DATA
Model MS-NC130-I Hose Crimper Machine
Crimping Range 14 - 87 (mm)
Crimping Force 650 (T)
Hose Size 1/4 - 2.5 (inch)
Max. Opening 31 (mm)
Die Sets 13
Die Set Type P32
System Pressure 31.5 (Mpa)
Accuracy 0.01 (mm)
Control MS
Standard Voltage 220 (V) / 380 (V)
Motor Power 3.75 (KW)
Length 650 (mm)
Width 550 (mm)
Height 1360 (mm)
Weight 310 (KG)
Hydraulic Hose Pressing Machine with 650T Crimping Force, 31.5Mpa System Pressure, and 14-87mm Crimping Range
P32 SERIES CRIMPER DIE SETS
Die No. Crimping Range Length
6* 6 - 8mm 55
8* 8 - 10mm 55
10* 10 - 12mm 55
12* 12 - 14mm 55
14 14 - 16mm 55
16 16-19mm 55
19 19 - 22mm 55
22 22 - 26mm 70
26 26 - 30mm 70
30 30-34mm 70
34 34 - 39mm 75
39 39 - 45mm 75
45 45 - 51mm 90
51 51 - 57mm 90
57 57 - 63mm 100
63 63 - 69mm 110
69 69 - 78mm 110
NOTE
  • * for non standard die sets
  • Customized die sets are available
  • Special voltage 110V, 208V, 240V, 415V are available
Hydraulic Hose Pressing Machine with 650T Crimping Force, 31.5Mpa System Pressure, and 14-87mm Crimping Range Hydraulic Hose Pressing Machine with 650T Crimping Force, 31.5Mpa System Pressure, and 14-87mm Crimping Range Hydraulic Hose Pressing Machine with 650T Crimping Force, 31.5Mpa System Pressure, and 14-87mm Crimping Range
