350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
Specifications
Brand Name :
OEM or CNHOPESTAR
Model Number :
HOP215WPC-8
Certification :
CE,ROHS, FCC,ISO9001,KC,CCC
Place of Origin :
Guangdong,China
MOQ :
100PCS
Price :
usd 315-319 /pcs
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
50000 pcs/month
Delivery Time :
2-8 working days
Packaging Details :
59x10x27cm
Screen size :
32 inch
Color :
Black
Interface type :
VGA and HDMI, RS232- optional
Type :
IR Touch , Capacitive Touch
Brightness :
350cd/m2 (1000cd/m2, optional)
Installation :
Kiosk, embeded, wall mount
3M :
Support
material :
metal
Name :
touch screen monitor
aplication :
pos
Description
PC Open Frame monitor hdmi USB Open Frame Touch Screen Monitor
  • Lilliput 32 inch Industrial Touch Screen Monitor Open Frame
  • 32" LED display panel with 1920*1080 native resolution
  • Application: - KIOSK / POS machine - Transportation machine
  • High contrast: 1500:1, High brightness: 300cd/m²
  • Viewing angle: 178° / 178° (H/V)
  • Faceplate surface: anti-glare coating and glare coating; Film thickness: 0.175 and 0.188mm; Glass thickness: 0.7, 1.1 and 1.8mm; Operation pressure: 20 to 150g; Storage temperature: -30 to 80¡ãC;Message noise: 5 to 15m/second; Operating current: 5 to 25mA; Humidity: <95%; Isolation resistance: 20M¦¸¡ü, 25V DC;Sealable against dust, water, oil and static; Advantages: Products insulation point is ¦µ0.03mm
  • Various choices of surface treatments available, special chemical strengthen hard coating,anti-reflection; Has our own factories,so our price is competitive; Excellent sales service; Applications: Light industry; Home appliances; Portable sport devices; Access control terminals; Portable medical devices , anti-Newton,
  • Different size optioanl from 10.4 inch to 32 inch
Specification
Display Specifications
CharacteristicValueComment
LCD Size/Type32”TFT-LCD　
Aspect Ratio16:9　
Active AreaHorizontal473.5mm　
Vertical297.4 mm　
PixelHorizontal0.24825　
Vertical0.24825　
Panel Resolution1920*1080Native
Display Color16.7 Million6-bits + Hi-FRC
Contrast Ratio1000:1Typical
Brightness350nitsTypical
Response Time5 msTypical
Viewing AngleHorizontal178Typical
Vertical178
Video Signal InputVGA and DVI , HDMI - optional　
Electrical Specifications
Power SupplyDC 12V 4APower Adapter Included
100-240 VAC, 50-60 HzPlug Input
Power ConsumptionOperating38 WTypical
Sleep3 W
Off1 W
Touch Screen Specifications
Touch TechnologyProject Capacitive Touch Screen 10 Touch Point
Touch InterfaceUSB (Type B)
OS SupportedPlug and PlayWin All (HID) ,Linux (HID) (Android Option)
DriverDriver Offered
Environmental Specifications
ConditionSpecification
TemperatureOperating-10°C ~+ 50°C
Storage-20°C ~ +70°C
HumidityOperating20% ~ 80%
Storage10% ~ 90%
MTBF30000 Hrs at 25°C
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
Touchscreen Specification
TypeIR Touch screen
Resolution4-wires/5-wires touch screen
Light Transmission92%
Touch Life Cycle50 millions
Touch Response time2ms
Touch System InterfaceUSB/RS232 interface
Power consumption+5V@80mA
350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor350nits 32 Inch Open Frame Touch Monitor / capacitive touch screen monitor
