Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Kiosk 15inch DC12v Open Frame Touch Screen Monitor VGA HDMI USB
Specifications
Brand Name :
OEM or Hopestar
Model Number :
HOP151
Certification :
CE,ROHS, FCC,ISO9001,KC,CCC
Place of Origin :
Shenzhen, China
MOQ :
100PCS
Price :
Price can be negotiable
Payment Terms :
T/T, L/C
Supply Ability :
50000 pcs/month
Delivery Time :
5~7 days
Packaging Details :
59x10x27cm
Screen size :
15 inch
Color :
Black
Resolution :
1024x768
Interface type :
VGA HDMI USB DC
Type :
Resistive Touch, 4-wires, 5-wires, capacitive
Brightness :
350cd/m2 (1000cd/m2, optional)
Installation :
embeded, wall mount
Warranty :
3 years
Description
Product Features
  • TOUCH READY - touch solution adopts the resistive touchscreen and the latest projected capacitive solution with (G+G) 10-point touch available ,it delivers great optical clarity and touch durability. 3mm thickness tempered cover glass provide front IK08 vandal-proof degree .
  • FEATUREED ELMENTS -The touch screen is sealed to prevent the bad influence from dirt, dust and liquid , can meet the front IP65 water-resistant requirement.
  • RICH INTERFACES - Coming with HDMI , VGA and Audio interfaces to meet different needs of various professional display application.
  • Various choices of surface treatments available, anti-Newton, -glare, special chemical strengthen hard coating,anti-reflection; Capable of handing spacer dots diameter is less than 0.035mm; Has our own factories,so our price is competitive; Excellent sales service; Applications: Light industry; Home appliances; Portable sport devices; Access control terminals; Portable medical devices
General Specifications
General
Series Open frame
LCD Type 15” TFT-LCD
Video Input VGA and HDMI
OSD controls Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: DC
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12v, 3A
Mount Interface 1)VESA 75mm and 100mm
2)2)Mount bracket, horizontal or vertical
LCD Specification
LCD Specification
Active Area(mm) 246.0(H)×184.5(V)
Resolution 1024*768
Dot Pitch(mm) 0.3075×0.3075
Nominal Input Voltage VDD +3.3V(Typ)
Viewing angle (v/h) 176°/170°
Contrast 1000:1
Luminance(cd/m2) 300, 1000cd/m2 optional
Response Time 5ms
Support Color 16.7M colors
Backlight MTBF(hr) 80000
Touchscreen Specification
Touchscreen Specification
Type Resistive touch screen
Resolution 4-wires/5-wires touch screen, capacitive touchscreen
Light Transmission 97%
Touch Life Cycle 50 millions
Touch Response time 2ms
Touch System Interface USB interface
Power consumption +5V@80mA
