Industrial Manufacturing 1000kg Beam Forklift With Adjustable Lifting Height And Speed
Industrial Manufacturing 1000kg Beam Forklift With Adjustable Lifting Height And Speed
Specifications
Place of Origin :
Guangdong Province
Brand Name :
HHD
Packaging Details :
Export Packaging
Delivery Time :
Within 20 days after downpayment
Payment Terms :
T/T 50% in advance,50% before shipment
Supply Ability :
150 sets / month
MOQ :
1set
Price :
2000–20000USD
Applications :
Apparel, Footwear,Industrial Manufacturing
Automation Level :
Semi-automatic
Control System :
Touch Screen/ Button Operation
Frame Material :
High-Strength Steel
Control Method :
Electronic Control + Manual Adjustment
Noise Level :
≤ 80 dB
Humidity Range :
≤ 85% RH
Description

Beam Forklift With Adjustable Lifting Height And Speed

Application Advantages:

Electric Stacker Forklift is widely applied in warehouses, factories, logistics hubs, and production lines. It is ideal for handling double-face pallets and operating in narrow aisles. The machine features high lifting efficiency, easy operation, and a smart power system, which significantly reduces labor costs and enhances productivity.

Key Features:
  • Virtually maintenance-free DC traction motor delivers powerful acceleration and steady performance while reducing downtime.
  • Ergonomic safety control handle enables smooth one-hand control for lifting and traveling, improving comfort and safety.
  • Built-in digital battery level gauge clearly displays power status in real time to avoid unexpected shutdowns.
  • Heavy-duty C-section mast frame ensures structural strength for intensive industrial use.
  • Key-operated On/Off control prevents unauthorized usage and enhances security.
  • Tandem load wheels designed for durability, smooth rolling, and continuous heavy-duty operation.
  • Sideways battery charger port offers fast and convenient battery charging and replacement.
  • Manual handle for steering provides smooth directional control in confined spaces.
  • Universal voltage battery charger (AC 110V -220V / 50-60Hz) adaptable to various electrical environments.
  • Standard VRLA battery ensures long service life, high safety, and zero maintenance.
  • Straddle-leg model available perfectly optimized for double-face pallets, enhancing stability and versatility.
Machine Technical Data
Model: HY-1025 / HY-1030 / HY-1525 / HY-1530
Load Capacity (Kg): 1000 / 1000 / 1500 / 1500
Load Center (mm): 500
Max. Lifting Height (mm): 2500 / 3000 / 2500 / 3000
Free Lift (mm): 0
Wheel Type: Polyurethane Solid Tire
Pedal Length (mm): 500
Fork Size (L×W) (mm): 1150 × 190
Width Between Forks (mm): 680
Overall Length (Pedal Closed) (mm): 2040
Overall Width (mm): 850
Overall Height (Mast Closed) (mm): 1805 / 2055 / 1805 / 2055
Overall Height (Fork Raised, with Backrest) (mm): 3036 / 3536 / 3036 / 3536
Outside Turning Radius (mm): 1725
Front Wheel to Fork Tip (mm): 330
Aisle Width for Pallet 800×1200 (Lengthways) (mm): 2480
Aisle Width for Pallet 1000×1000 (Crossways) (mm): 2460
Lift Speed (Laden/Unladen) (mm/s): 70 / 108
Lowering Speed (Laden/Unladen) (mm/s): 78
Battery Weight (Kg): 200
Max. Walking Speed (Km/h): 4.0 / 5.8
Gradeability (%): 8
Total Weight (With Battery) (Kg): ~935 / ~950 / ~940 / ~950
Driving Wheel (mm): Φ215 × 75
Front Wheel (mm): Φ80 × 70
Balance Wheel (mm): Φ150 × 50
Battery (V/Ah): 24 / 210
Charger (V/A): 24 / 30
Driving Motor Power (Kw): 1.5
Lifting Motor Power (Kw): 2.0
Battery Dimensions (mm): 650 × 200 × 585
