1D 2D Mobile QR Payment Barcode Scanner Module Sunlight Resistant Long Range
1D 2D Mobile QR Payment Barcode Scanner Module Sunlight Resistant Long Range
1D 2D Mobile QR Payment Barcode Scanner Module Sunlight Resistant Long Range
1D 2D Mobile QR Payment Barcode Scanner Module Sunlight Resistant Long Range
1D 2D Mobile QR Payment Barcode Scanner Module Sunlight Resistant Long Range
1D 2D Mobile QR Payment Barcode Scanner Module Sunlight Resistant Long Range
Specifications
Brand Name :
HONORWAY
Model Number :
HW-1560D
Certification :
CE ROHS FCC ISO9001
Place of Origin :
China
MOQ :
2
Price :
12
Payment Terms :
T/T
Supply Ability :
10Kpcs/month
Delivery Time :
3-7days
Product Name :
Sunlight Resistant Long Range Barcode Reader Module
Resolution :
0.3MP 752*480pixels
Scan Angle :
Rotation360°,tilt±50°,skew±50°
Working Voltage :
DC 5V or 3.3V
Dimensions :
54.5 x 33.3 x 14 ( L x W x H)
Typical DOF :
30-500mm(25mil QR 4*4cm screen)
Features :
Sunshine readable, long reading distance
Application :
Parking system under sunshine,Kiosk
Description
Sunlight Resistant Long Range 1D 2D Mobile QR Payment Barcode Scanner Module
Long-Range Embedded Barcode Scanner with Anti-Glare Technology for Outdoor Payment

The HW-1560D is a compact 0.3MP global shutter barcode scanner module engineered for reliable 1D and 2D barcode reading in challenging lighting conditions. A black light-absorbing layer around the camera filters out spectral interference, ensuring accurate decoding even under direct sunlight.

Key Performance Features
  • Extended read range up to 60cm for mobile QR codes
  • 45cm reading distance in full sunlight conditions
  • Anti-sunlight technology with light-absorbing filter layer
  • Global shutter exposure for high-speed scanning
  • Compact design: 54.5 x 33.3 x 14 mm, 11g weight
Technical Specifications
Parameter Specification
Image Sensor CMOS
Exposure Global shutter
Resolution 0.3MP (752×480 pixels)
Decoding Capacity Supports paper and screen barcodes
2D Barcode Support QR, MICROQR, PDF417, MICROPDF417, DATAMATRIX, MAXICODE, AZTEC, HANXIN
1D Barcode Support Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Interleaved 2 of 5, ISBN, ISSN, ITF6, ITF14, Codebar, Code 93, UCC/EAN-128
Precision 4mil
Light Source LED (630nm±10nm)
View Angle 68°(H) × 51°(V)
Scan Angle Rotation 360°, tilt ±50°, skew ±50°
Minimum Contrast 30%
Anti-Sunlight Supported
Typical Depth of Field 20-150mm (13mil EAN13)
25-150mm (15mil QR)
30-500mm (25mil QR 4×4mm screen)
20-90mm (7mil PDF417)
Interface RS232 (DB9, open wire), USB (HID, COM), TTL232 (UART)
Working Voltage DC 5V
Current 250mA (Max), 100mA (standby), 1mA (sleep)
Dimensions 54.5 × 33.3 × 14 mm (L × W × H)
Weight 11g (without cable)
Indication Buzzer & LED
Primary Applications

Deployed across sun-exposed self-service terminals, the HW-1560D is ideally suited for drive-up payment scenarios such as parking lot exits and gas stations. Drivers can simply present their mobile QR code from inside the vehicle, with the scanner maintaining reliable read distances of over 40cm even under intense sunlight—eliminating the need to exit the car and streamlining the payment experience.

Ideal For:
  • Self-service kiosks in outdoor environments
  • Drive-up payment systems
  • Parking lot exit terminals
  • Gas station payment systems
  • High-volume deployment scenarios
