Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection
Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection
Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection
Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection
Specifications
Brand Name :
Jingtan
Place of Origin :
Hunan, China
MOQ :
1
Price :
$42,000
Voltage :
380
Weight :
4 t
Limit Temperature :
2400℃
Heating Method :
Resistance graphite rod heating
Control Model :
Manual or automatic
Working Atmosphere :
Vacuum or inert gas protection
Working Temperature :
2200℃
Temperature Measurement :
Far infrared
Furnace Structure :
Horizontal
Furnace Material :
SS 304
Cooling System :
Closed water cooling tower
Temperature Difference :
±5 to ±15
High Temperature Zone :
300*300*500 to 1500*1500*5200 mm
Loading Capacity :
45 to 11700
Core Components :
PLC, Pressure vessel, Pump, Cylinder
Description
Large Volume Loading Capacity Working Zone Direct Heating Carbonization Activation Purity Sintering Furnace
Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection
Carbon Nanotube Purification Furnace
The combined purification treatment of high temperature method and chemical method. Suitable for new energy vehicles, semiconductors, new materials and many other fields.
Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection
Heat treatment of battery anode materials, powder metallurgy, nanomaterials, graphene, new materials and powder materials in vacuum atmosphere, and high temperature sintering and purification in an inert atmosphere.
Model TCL-45 TCL-128 TCL-375 TCL-720 TCL-1568 TCL-2560 TCL-5000 TCL-7200 TCL-11700
High Temperature Zone (mm) 300*300*500 400*400*800 500*500*1500 600*600*2000 700*700*3200 800*800*4000 1000*1000*5000 1200*1200*5000 1500*1500*5200
Loading Capacity 45 128 375 720 1568 2560 5000 7200 11700
Temperature Difference ±5 ±10 ±15
Limit Temperature 2400
Heating Mode resistance graphite rod heating
Control Model manual or automatic operation
Working Atmosphere in the Furnace vacuum or inert gas protection (micro positive pressure)
  • It can be used for high temperature graphitization purification of carbon nanotube materials, and can realize the purification treatment of high temperature method combined with chemical method.
  • It can realize continuous feeding and discharging at high temperature, reducing energy consumption and shortening production cycle.
  • Use resistance or induction heating, the temperature can reach 2400℃.
  • The combination of high temperature method and chemical method can meet the requirements of high purity treatment.
  • The efficient filtration system can effectively capture the dust and corrosive gases produced in the purification process.
  • It can realize continuous feeding and discharging at high temperature, reducing energy consumption and shortening production cycle.
Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Large Volume 5000L Loading Capacity Continuous Carbon Nanotube Purification Furnace with 2400℃ Limit Temperature and Vacuum or Inert Gas Protection

Frequently Asked Questions
Are you a factory or trading company?
Yes, we are China leading high-temperature vacuum furnace manufacturer with 14+ years experience, granted with many patent certifications in the domestic market.
Do you have customization or OEM service?
Yes, we have powerful R&D team and high-tech equipment. We can supply both regular models and customizable furnaces according to client requirements.
What's your advantages?
  • Quick response to your enquiry
  • High quality control
  • Stable supply chain in the domestic market
  • Timely delivery
  • Excellent after-sales service, including engineer dispatch for installation and debugging
