Specifications
Place of Origin :
Hunan, China
Brand Name :
Jingtan
MOQ :
1
Price :
$40,000
Type :
Induction Furnace
Voltage :
380
Weight :
8 t
Maximum Temperature :
2400 ℃
Heating method :
resistance heating
Furnace atmosphere :
Vacuum or inert gas protection (slightly positive pressure)
Furnace structure :
horizontal
Furnace material :
SS 304
Temperature measurement :
far infrared
Working temperature :
2200
Output range :
50-200 kg/h
Control method :
Manual or automatic operation
Loading capacity :
10-250 L
Temperature difference :
±3.5 to ±8 ℃
Core components :
PLC
Description

Carbon nanotube purification furnace:
The carbon nanotube purification furnace can be used for high-temperature graphitization purification of carbon nanotube materials, and can realize the purification treatment combining high temperature method and chemical method.
It is suitable for various fields such as new energy vehicles, semiconductors, new materials, etc
Model
GJC-DCL-4
GJC-DCL-10
GJC-DCL-15
Out put（kg/h）
50-90
100-140
150-200
Maximum Temperature（℃）
2400
Heating method
resistance graphite rod heating
Control method
Manual or automatic operation
Loading Capacity（L）
10-40
40-120
120-250
Temperature difference in constant temperature Zone（℃）
±3.5
±5
±8
Furnace working atmosphere
Vacuum or inert gas protection (slightly positive pressure)

Application 1:

For heat treatment or purification of lithium battery anode graphite material,nanomaterials,new material sintering and purifide at very high temperature under vacuum or atmosphere protective furnace.

Application 2:

For heat treatment or purification of powder metallurgy,graphene and other powder materials under vacuum or atmosphere protective furnace.

Fetures:

It can be used for high-temperature graphitization purification of carbon nanotube materials, and can realize the purification treatment of high-temperature method combined with chemical method.
Adopting resistance or induction heating, the temperature can be up to 2400℃;

Fetures:

Can realize continuous feeding and discharging at high temperature, which reduces energy consumption and shortens production cycle;
Adopting high-efficiency filtration system, which can effectively trap dust and corrosive gas generated during the purification process;

Are you a factory or trading company?

Q: Are you a factory or trading company?
A:Yes,we are China leading high-temperature vacuum furnace manufacturer 14+years,granted with many patent certifications in the domestic market.

Do you have customization or OEM service?

Q: Do you have customization or OEM service??
A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.

What's your advantages?

Q:What's your advantages?
A:Quick response to your enquiry
High quality control
Stable supply chain in the domestic maket
Timely delivery
Excellent after-sales service,we can dispatch our engineer to the customer city for installation and debugging.
