Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Specifications
Price :
$42,000
Furnace Body Material :
SS 304
Rated Power :
80-180 kw
Operating Temperature :
≤2400℃
Max Temperature :
3000℃
Temperature Control :
PID automatic control
Type :
Resistance Furnace
Limit Temperature :
2400℃
Temperature Measurement :
thermocouple or infrared
Weight :
5 t
Protective Gas :
argon
Heating Rate :
200℃/ hour
Production Output :
100-200 kg/d
Brand Name :
Jingtan
Voltage :
three phase 380v
Boat Size :
φ100*320 to φ200*420 mm
Place of Origin :
Hunan, China
Cooling Mode :
circulating water cooling
MOQ :
1
Description
High Efficiency Industrial Furnace for Vacuum Carbon Tube Purification and Sintering

Excellent performance at high temperatures with maximum operating temperature of 2800℃.

Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Product Overview

This high-temperature carbon tube furnace is primarily designed for graphite powder purification and other high-temperature treatments. Capable of continuous long-term operation at temperatures up to 2800℃, it features excellent production efficiency and energy-saving performance.

Key Features
  • On-line temperature measurement and control system for real-time monitoring and automatic adjustment
  • PID automatic temperature control for precise regulation
  • Far-infrared temperature measurement technology
  • Circulating water cooling system
  • Push-boat type intermittent loading materials
  • Three-phase 380V power supply
Technical Specifications
Model JT-TGL-100 JT-TGL-150 JT-TGL-200
Operating Temperature ≤2400℃
Boat Size (mm) φ100*320 φ150*400 φ200*420
Production Output (kg/d) 100 150 200
Protective Gas Argon
Rated Power (kw) 80 150 180
Advanced Features
  • Temperature uniformity with long constant temperature area
  • Extended furnace tube lifespan (20-30 days continuous operation)
  • Infrared temperature measurement with PID automatic control
  • Stable three-phase power supply
  • Maximum temperature capability of 3000℃
  • Automatic feeding device
  • Carbon felt insulation for easy maintenance
  • Push-boat production mode for continuous operation
  • Stainless steel construction for durability
  • Vacuum pump for efficient gas replacement
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Company Information
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Certifications and Patents
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Production Process
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Customer References
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Logistics and Shipping
Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification Industrial Continuous Furnace with 2800℃ Max Temperature, PID Automatic Control, and Circulating Water Cooling for Graphite Powder Purification
Frequently Asked Questions
Are you a factory or trading company?
Yes, we are China's leading high-temperature vacuum furnace manufacturer with 14+ years of experience, granted with many patent certifications in the domestic market.
Do you have customization or OEM service?
Yes, we have a powerful R&D team and high-tech equipment. We can supply both standard models and customized furnaces according to client requirements.
What are your advantages?
  • Quick response to enquiries
  • High quality control standards
  • Stable domestic supply chain
  • Timely delivery
  • Excellent after-sales service including on-site installation and debugging
