45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
45S 100A Bms Battery Management System Lifepo4 High Voltage 144V
Specifications
Brand Name :
GCE
Model Number :
RBMS07S45S100A
Certification :
CE/RoHS/MSDS/
Place of Origin :
China
MOQ :
2
Price :
can be renegotiate
Supply Ability :
1000 set per month
Delivery Time :
15-20 day
Packaging Details :
Carton or additional wooden package
Product Name :
Integrated BMS
Current :
100A
Voltage :
144V
Number of battery strings :
45S（4 x 15 S）
Communication :
CAN, RS485
Warranty :
3 years
Design :
Slave and master BMS all in one
Life Span :
Long life cycle, >3000 times at 80% DOD.
Description

GCE 45S 144V 100A Lifepo4 BMS Battery High Voltage Battery Management Energy Storage System

45S 100A Bms Battery Management System Lifepo4 High Voltage 144V

Model No.:RBMS07S60S100A

1.It is high integrated with less installation space.

2.Long life cycle, >3000 times at 80% DOD.
3.It without heavy metals and
environment friendly.
4.Maintenance free,there is no memory effect.
5.Internal BMS with full protection,battery has high voltage protection with higher reliability.
6. Master and Slave all in one.

Specification:

Model no.: RBMS07S60S100A
System voltage range: 120 - 228 V DC
Startup mode: DC start (optional AC and DC starter)
Number of battery strings: 75 S(5 x 15 S)
Balance: Equilibrium type , Passive resistance equalization
Balanced current: 100mA ± 10mA(Single cell 3.4V ,
Temperature Sampling Numbers: 12 Battery temperature(4*3)
Sampling accuracy: ± 2℃
Voltage Sampling: Sampling accuracy
Single cell: ±20mV
SOC: ≤5% ,
Communication mode:
CAN: 1 channel (communication with PCs / UPS)
RS485: 1 channel (communication with upper computer / PCS / UPS)
Bluetooth: optional (android app available)
GPRS: optional,
Display mode:
6-digit LED indicator,
including 1-bit fault indication,
1-bit operation indication,
4-bit SOC power indication
HMI display: optional
Protection level:
2 two levels
Level 1 cut off charge / discharge
Level 2 micro cut-off switch, system power down
Operating Temperature:
Charging : －10～75℃
Discharging : -20 to 75℃
Storage : -40 to +75℃

item
value
Place of Origin
China
Hunan
Application
Solar Energy Storage Systems,Electric Folklifts, Golf Carts
Brand Name
GCE
Model Number
45 S(3 x 15 S)
Model
BMS(Battery Management System)
Design
Slave and master BMS all in one
Voltage
144V
Current
100mA ± 10mA
Strings
45s
Communication
CAN, RS485
Size
410*232*128mm
Application
Solar Energy Storage Systems,Electric Folklifts, Golf Carts
BMS(Battery Management System)
Lithium iron phosphate battery
Warranty
3 years
