Paper Industry Water Reclamation Systems Industrial Water Reclamation System Customized
Paper Industry Water Reclamation Systems Industrial Water Reclamation System Customized
Specifications
Brand Name :
HongJie
Place of Origin :
Shenzhen,China
MOQ :
>=1sets
Price :
negotiation
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Flow Rate :
0.25m³/h - 200m³/h (customizable )
Produced Water Quality :
Conductivity ≤ 15μs/cm
Core Technolog :
RO+UF
Key Components :
RO Membrane Module + UF Membrane Module
Operation Mode :
Full automatic (PLC-controlled)
Product Features :
Stable Water Quality,Low Operation Cost,Reliable Performance
After-Sales Service :
24/7 Technical Support, 2-Year Warranty and Maintenance
Power Supply :
380V
Description

I. Equipment Overview

Paper manufacturing wastewater originates primarily from two processes: pulping (separating fibers from plant materials, bleaching to form pulp) and paper making (diluting pulp, forming, pressing, and drying). Our reclaimed water reuse system employs a four-stage treatment process—wastewater treatment station, adjustment tank, microfiltration/ultrafiltration, and modified RO membrane filtration—to recycle water that meets Urban Wastewater Reuse - Industrial Water Quality standards and factory-specific requirements. This solution significantly reduces water consumption, cuts production costs, and addresses energy-saving & emission-reduction goals.

II. Process Flow

Wastewater → Adjustment Tank → Microfiltration → Ultrafiltration → Modified RO Membrane → Reclaimed Water Tank

III. Design Highlights (Marketing Focus)

  1. Intelligent Automation – Full PLC control with manual override, auto-scheduled backwashing/regeneration for unattended operation.
  2. Corrosion-Resistant Materials – UPVC pipelines for durability and low maintenance.
  3. Integrated Control System – Centralized monitoring dashboard for real-time water quality and process management.
  4. Smart Maintenance Alerts – Auto-notification for consumable replacement based on water quality & pressure changes (not just usage time), adapting to regional water variations.
  5. Superior Separation Efficiency – Membrane technology achieves precise solid-liquid separation, removing suspended solids, colloids, and microorganisms without tertiary treatment for direct reuse.
  6. High-Concentration Biomass Treatment – Maintains optimal microbial density in bioreactors, reducing hydraulic retention time and footprint by 50% compared to traditional systems.
  7. Enhanced Biological Treatment – Preserves slow-growing bacteria (e.g., nitrifying bacteria), enabling complete metabolic processes for difficult-to-degrade pollutants.
  8. Extended Retention for Macromolecules – Targeted design breaks down complex organics that traditional methods struggle to process.
  9. Long-Life Membrane System – Engineered for minimal fouling, with automatic backwashing and chemical cleaning protocols to sustain MBR performance over 5+ years.

IV. Design Standards & Basis

  1. Tailored solutions based on clients’ detailed water quality reports
  2. JB/T 2932-1999 Technical Conditions for Water Treatment Equipment
  3. CJ/T95-2000 Standards for General Landscape & Ecological Water Use
  4. CJ/48-1999 Standards for Non-potable Domestic Water Use (Ministry of Construction)
  5. GB/T50102-2003 Standards for Industrial Circulating Cooling Water
  6. CJ/T119-2000 Standards for Reverse Osmosis Water Treatment Equipment
  7. IEC439-1 Low-voltage Switchgear and Controlgear Assemblies
