15m³/H Industrial Wastewater Filtration System for Textile Dyeing
15m³/H Industrial Wastewater Filtration System for Textile Dyeing
Specifications
Brand Name :
HJW
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Shenzhen,China
MOQ :
1set
Price :
1set
Payment Terms :
L/C,D/P,T/T,Western Union
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Capacity :
15m³/H
Material :
316 L，PP，UPVC，PVDF ，FRP
TDS :
< 2000 mg/L
COD :
1000 - 15000 mg/L
pH :
6 - 9
HS code :
84212199
Description

I.Overview
Textile/printing and dyeing industry wastewater has high color, high COD, difficult to degrade organic matter (such as dyestuffs, auxiliaries), high salinity (such as desizing wastewater) and heavy metals (such as mordant), etc., and the treatment needs to be combined with physicochemical and biochemical technologies, and according to the type of dyestuffs and auxiliaries, the composition of the reuse of the demand for a flexible combination of processes, and the selection of corrosion-resistant, oxidation-resistant materials in order to cope with the complexity of the water quality.


II.Main process
Pre-treatment → Physical treatment (for difficult to degrade substances)→ Biological treatment → Deep treatment and reuse → Sludge treatment


III.Equipment Material Selection

Processing Stage Equipment Material Selection
Pretreatment Stage Grille/Screen 316 stainless steel (corrosion-resistant)
Coagulation Reaction Tank PP (polypropylene) or FRP (fiberglass-reinforced plastic), resistant to acids, alkalis and chemical corrosion
Dissolved Air Flotation Equipment Main body: SS304; Dissolved air tank: carbon steel with rubber lining
Physicochemical Treatment Stage Fenton Reactor Titanium or HDPE lining (resistant to strong oxidization)
Ozone Generator 316L stainless steel (oxidation-resistant)
Activated Carbon Filter Carbon steel lined with epoxy resin or UPVC
Biological Treatment Stage Anaerobic Reactor (UASB) Carbon steel lined with fiberglass-reinforced plastic or PP material
MBR Membrane Module PVDF membrane + stainless steel support (pollution-resistant)
Aeration System EPDM aeration pipe + UPVC pipeline
Advanced Treatment Stage RO Membrane Housing FRP or SS316; Membrane element: polyamide composite membrane
Electrochemical Equipment Titanium electrode (corrosion-resistant)
Sludge Treatment Stage Dewatering Machine Centrifuge: duplex stainless steel; Plate and frame filter press: PP filter plate


IV.Core Attribute Parameters

Parameter Typical Range/Requirement Significance
COD 1000 - 15000 mg/L Determines the selection of oxidation or biochemical processes
Chroma 500 - 5000 times (dilution multiple) Requires physical and chemical decolorization (coagulation, oxidation, adsorption)
pH 6 - 9 (suitable range for biological treatment) Strong acid/alkali wastewater requires neutralization pretreatment
Salt Content (TDS) < 2000 mg/L (reuse requirement) High - salt wastewater requires membrane treatment or evaporation concentration
BOD5/COD < 0.3 (requires hydrolysis and acidification enhancement) Evaluates the biodegradability of wastewater
Heavy Metals (Cr, Cu) < 0.5 mg/L (discharge standard) Requires chemical precipitation or electrochemical treatment


V.Typical application scenarios
Cotton printing and dyeing
Chemical fiber printing and dyeing
Denim dyeing (indigo wastewater)
Printing wastewater


VI.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
