SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump
Specifications
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
Engine, Motor, Pump
Place of Origin :
Shandong,China
Brand Name :
KOMAMAX
Model Number :
SD16, SD16
Moving Type :
Crawler Bulldozer
Machine Weight :
16400 KG
Dimension(Long * Breadth * High) :
4990*3440*3110
Dozing Capacity :
7.5m³, 5m³, 7.8m³, 5.4m³, 4.3m³, 4m³, 8.6m³, 6.5m³, 6m³, 10m³, 4.5m³
Warranty :
1 Year
Hydraulic Cylinder Brand :
JF
Hydraulic Pump Brand :
JF
Hydraulic Valve Brand :
JF
UNIQUE SELLING POINT :
JF
Product name :
SD16R Bulldozer
Type :
Crawle Bullldozer
Condition :
Working, New
Brand :
KOMAMAX
Customized Service :
Support
Product Packaging :
Original Package
HS Code :
8431420000
Production Capacity :
5000/Year
Specification :
5140*3388*3032
Applicable Industries :
Other
Showroom Location :
None
Marketing Type :
Ordinary Product
Port :
Qingdao Port; Tianjin Port; Shanghai Port
Supply Ability :
800 Set/Sets per Month
Price :
$69,700.00/units 1-4 units
MOQ :
1 set
Description
Product Description

SD16 STANDARD BULLDOZER MAIN TECHNICAI PARAMETERS
Model number SD16
Length × width × height (mm)
(without ripper)		 4990×3440×3110
Service weight (kg)
(without ripper)		 16400
Engine type WD10G178E25
WP10G178E355
Power/rated revolutions
(kw/rpm)		 131/1850
Grounding length and specific grounding pressure
(MPa)		 2430
0.067
Climbing performance
(° )		 30
Number of track plates
(each side)		 37
Track plate width
(mm)		 510(560,610)
Track center distance
(mm)		 1880
Chain track pitch
(mm)		 203.2
Number of supporting wheels
(each side)		 2
Number of wheels supported
(each side)		 6
Blade type Straight tilting shovel
Blade length x height
(mm)		 3440×1135
Blade capacity (m3) 4.5
Blade lift height
(mm)		 1095
Blade depth
(mm)		 540
Ripper type tridentate
Depth of soil loosening
(mm)		 570
The ripper raises the height
(mm)		 600
Forward gear speed (km/h) F1:0~3.29
F2:0~5.82
F3:0~9.63
Reverse all gears (km/h) R1:0~4.28
R2:0~7.59
R3:0~12.53

SD16 hydraulic drive series bulldozer, with high scientific and technological content, advanced and reasonable design, strong power, high production efficiency, can adapt to more harsh working environment, easy maintenance.


Suitable for road, railway, mine, airport and other ground pushing, excavation, backfill earth and stone and other bulk material operations, is national defense engineering, mine construction, urban and rural roads and other construction and water conservancy construction indispensable construction machinery.

Product Overviews

SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump

SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump

Packaging & Shipping

SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump

Our Project

SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump

Certifications

SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic PumpSD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump SD16 Big Bulldozer Pushdozer Earthmover with 4m3 Dozing Capacity and JF Hydraulic Pump

Company Information

Shandong Hengjianhang Construction Machinery Co., Ltd.

Shandong Hengjianhang Construction Machinery Co., Ltd. was established in 2008, wholesale and retail Mini Excavator,Tamping Rammer,Plate Compactors,Power Trowel,Crack Sealing Machine,Vibratory Roller,Mini Crawler Dumper,Cutting Equipment,Mini Skid steer loader, Bulldozer and excavator hydraulic pumps, final drives, hydraulic cylinder seal kits, Arm Boom Bucket, seal kits, O-ring kits, engine liner kits, cylinder heads, cylinder blocks, crankshafts, camshafts, connecting rods, con rod bearings, valves, gasket kits, excavator & dozer track link assy, idlers, sprockets, track rollers, carrier rollers, buckets, tooth, bolts, nuts, engine, engine related parts, cooling system, fuel tank and related parts, electrical system, hydraulic system and so on...
