Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Specifications
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
1 Year
Core Components :
Engine, Motor, Gear
Place of Origin :
Shandong, China
Brand Name :
JF
Model Number :
SD32
Moving Type :
Crawler Bulldozer
Machine Weight :
24500 KG
Dimension(Long * Breadth * High) :
5600*3725*3400
Dozing Capacity :
6m³
Warranty :
1 Year
Hydraulic Cylinder Brand :
JF
Hydraulic Pump Brand :
JF
Hydraulic Valve Brand :
JF
UNIQUE SELLING POINT :
With soil loosening tools and bulldozing
Product name :
SD22 Bulldozer
Color :
Yellow
Rated power / rated speed (kW / rpm) :
175/1800
Engine Model :
Cummins
Blade type :
Straight, angle, U, and half-U
Blade Capacity :
6.5m³
Feature :
High Working Efficiency
Walking Mode :
Crawler Moving
Max speed :
11.2 km/h
Applicable Industries :
Building Material Shops
Price :
$136,900.00/sets 1-9 sets
MOQ :
1 set
Description
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Company Profile
Product Paramenters
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Type section
SD22
Long, X, width, X height (mm) (excluding soil)
5390x3735x3350
Weight used (excluding loosening) (kg)
23500
engine type
NT855-C280S10
Power / rated turn quantity (kw/rpm）
175/1800
Ground length and ground specific pressure (MPa)
2730
0.077
Climbing performance of (°)
30
Number of track boards (on each side)
38
Crawle plate width (mm)
560
Crawler center distance (mm)
2000
Chain rail pitch (mm)
216
Number of carriers (each side)
2
Number of heavy wheel bearings (each side)
6
Shovel knife type
Straight, angle, U, and half-U

Shovel length x high (mm)
Straight:3735X 1310
Corner:4365X1057
U:3800X 1345
Half-U: 3725 X 1376
Shovel blade capacity (m³)
Straight:6.4 Corner:4.7 U7.5 Half-U:7
Shoade lift height (mm)
1210
Shovel depth (mm)
540
Relaxed soil type
Single teeth three teeth
Depth (mm)
Single tooth: 695. Three teeth: 666
Looiser lifting height (mm)
Single tooth: 515. Three teeth: 555


Forward speed (km/h)
F1:0~3.6
F2:0~6.5
F3:0~11.2


Backgear speed (km/h)
R1:0~4.3
R2:0~7.7
R3:0~13.2
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Products Description
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension

Click here for more details
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Exhibition
FAQ
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
Product packaging
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension

Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension

Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension

Packing & Delivery
Shantui Dozer SD32 HD32 320HP with Cummins Engine Model and 5600*3725*3400 Dimension
