1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
Specifications
Model Number :
Customizable
Material :
SiC
Composition:SiC :
＞85%
Color :
Black
Density :
2.5~2.6g/cm³
Max. Service Temp :
1380℃
Flexural Strength :
70-90 MPa
Size :
Customized
Heat Conduction :
23.26 W/(m·℃)
Resistivity :
1000～2000 Ω·mm2/m
Tensile Strength :
39.2～49 MPa
Max. Service Temp. :
1500℃
Linear Thermal Expansion Coefficient (20-1500℃) :
5×10⁻⁶/℃
Electrical Resistivity :
1000~2000Ω·mm²/m
Brand Name :
KEGU
Place of Origin :
China
Price :
200-500 yuan/kg
Payment Terms :
L/C,D/A,D/P,T/T,,
Supply Ability :
2,000 pcs/month
Packaging Details :
Strong wooden box for Global shipping
Description
1500°C SiC Resistance High Temperature Heating Element - Double Helix Type
High-performance silicon carbide heating elements designed for extreme temperature applications up to 1500°C, featuring double helix construction for optimal heat distribution and efficiency.
1500℃ Max Service Temp SiC Heating Element Double Helix Type Corrosion Resistant for High Temperature Furnaces
Product Overview
  • Production Process: Manufactured from blanks, silicided under high temperature, and re-crystallized
  • Key Characteristics: High temperature resistance, oxidation resistance, corrosion resistance, long service life, minimal deformation, easy installation and maintenance
  • Applications: Ideal for high temperature electric furnaces and heating devices in magnetic, ceramic, metallurgical, glass, and machinery industries
Physical Properties
Specific Gravity 2.6~2.8 g/cm³ Bend Strength >300 kg
Hardness >9 MOH'S Tensile Strength >150 kg/cm³
Porosity Rate <30% Radiancy 0.85
Usage Guidelines
  1. Conduct resistance distribution testing before installation to ensure uniform furnace temperature and charge distribution
  2. Handle with care during installation and maintenance as elements are brittle and susceptible to damage
  3. When starting furnace operation, gradually increase voltage - never apply full load immediately
Technical Specifications
Required Information for Specification:
  • Type
  • OD: Outer Diameter
  • HZ: Hot Zone
  • CZ: Cold Zone
  • OL: Overall Length
  • Resistance (Ohms - Ω)
Standard Dimensions & Resistance Ranges
Outer Diameter (mm) Hot Zone (mm) Cold Zone (mm) Overall Length (mm) Resistance Range (Ω)
8100-30060-200240-7002.1-8.6
12100-400100-350300-11000.8-5.8
14100-500150-350400-12000.7-5.6
16200-600200-350600-13000.7-4.4
18200-800200-400600-16000.7-5.8
20200-800250-600700-20000.6-6.0
25200-1200250-700700-26000.4-5.0
30300-2000250-800800-36000.4-4.0
35400-2000250-800900-36000.5-3.6
40500-2700250-8001000-43000.5-3.4
45500-3000250-7501000-45000.3-3.0
50600-2500300-7501200-40000.3-2.5
54600-2500300-7501200-40000.3-3.0
Key Features
  • Withstands temperatures up to 1600°C
  • High strength with excellent shock resistance
  • Noise-free, pollution-free heat source
  • Superior oxidation and corrosion resistance
  • Easy installation and maintenance
Ordering Information
Please provide the following details when placing your order:
  1. Type: rod, U, W, H, spiral, or double-spiral
  2. OD, HZ, CZ, OL dimensions
  3. For U or W types, specify terminal distance
  4. Any special resistance requirements
  5. Quantity needed
Industrial Applications
  • Thermoforming & Vacuum Forming Machines
  • PVC Pipe Belling / Socketing Machines
  • Hot Stamping Machines
  • Heat Therapy Equipment
  • Shrink Packaging Systems
Quality Assurance
