High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
Specifications
Model Number :
Customizable
Material :
SiC
Composition:SiC :
＞85%
Color :
Black
Density :
2.5~2.6g/cm³
Max. Service Temp :
1380℃
Flexural Strength :
70-90 MPa
Size :
Customized
Heat Conduction :
23.26 W/(m·℃)
Resistivity :
1000～2000 Ω·mm2/m
Tensile Strength :
39.2～49 MPa
Max. Service Temp. :
1500℃
Linear Thermal Expansion Coefficient (20-1500℃) :
5×10⁻⁶/℃
Electrical Resistivity :
1000~2000Ω·mm²/m
Brand Name :
KEGU
Place of Origin :
China
Price :
200-500 yuan/kg
Payment Terms :
L/C,D/A,D/P,T/T,,
Supply Ability :
2,000 pcs/month
Packaging Details :
Strong wooden box for Global shipping
Description
High-Temperature Silicon Carbide (SiC) Heating Elements
Our premium Silicon Carbide (SiC) heating elements are engineered for extreme conditions, offering superior performance, exceptional longevity, and consistent heat up to 1600°C. Ideal for industrial furnaces and high-temperature processing applications.
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
Product Specifications & Sizing Guide
Find the perfect element for your furnace with our comprehensive sizing chart. All dimensions are in millimeters (mm).
Outer Diameter (mm) Hot Zone (mm) Cold Zone (mm) Overall Length (mm) Range of Resistance
8100-30060-200240-7002.1-8.6
12100-400100-350300-11000.8-5.8
14100-500150-350400-12000.7-5.6
16200-600200-350600-13000.7-4.4
18200-800200-400600-16000.7-5.8
20200-800250-600700-20000.6-6.0
25200-1200250-700700-26000.4-5.0
30300-2000250-800800-36000.4-4.0
35400-2000250-800900-36000.5-3.6
40500-2700250-8001000-43000.5-3.4
45500-3000250-7501000-45000.3-3.0
50600-2500300-7501200-40000.3-2.5
54600-2500300-7501200-40000.3-3.0
Note: Custom dimensions and resistance values are available upon request.
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
Key Features & Benefits
  • Withstands Extreme Temperatures: Reliable operation up to 1600°C (2912°F) for the most demanding processes
  • High Mechanical Strength: Excellent shock resistance and structural integrity for long service life
  • Clean & Quiet Heat Source: Produces no noise or air pollution, ensuring a better working environment
  • Superior Durability: Anti-oxidation and anti-corrosion properties reduce degradation and maintenance costs
  • Easy Installation & Maintenance: Designed for straightforward integration and servicing to minimize downtime
How to Place Your Custom Order
To ensure you receive the correct SiC heating element, please provide the following information:
  • Type: Rod, U-Type, W-Type, H-Type, Spiral, or Double-Spiral
  • Critical Dimensions: Outer Diameter (OD), Hot Zone (HZ), Cold Zone (CZ), and Overall Length (OL)
  • Terminal Distance (For U/W Types): Specify the required center-to-center terminal distance
  • Specific Resistance (If required): Inform us of any precise resistance (Ω) requirements
  • Quantity: Your required volume for accurate pricing
Uncompromising Quality Control
Every Silicon Carbide heating element undergoes rigorous testing to guarantee performance, dimensional accuracy, and electrical properties. We provide quality inspection reports to ensure you receive components you can trust.
Primary Applications
  • Industrial & Laboratory Electric Furnaces
  • Sintering, Annealing, and Heat Treatment Processes
  • Ceramics, Glass, and Metallurgy Industries
  • Thermoforming & Vacuum Forming Machines
  • PVC Pipe Belling / Socketing Machines
  • Hot Stamping Machines
  • Heat Therapy Equipment
  • Shrink Packaging Systems
High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life High-Temperature SiC Heating Elements for Ovens with 1500°C Max Service Temp Anti-Corrosion and Long Life
