Specifications
Material :
SiC
Composition:SiC :
＞85%
Color :
Black
Density :
2.5~2.6g/cm³
Max. Service Temp :
1380℃
Flexural Strength :
70-90 MPa
Size :
Customized
Heat Conduction :
23.26 W/(m·℃)
Resistivity :
1000～2000 Ω·mm2/m
Tensile Strength :
39.2～49 MPa
Max. Service Temp. :
1500℃
Linear Thermal Expansion Coefficient (20-1500℃) :
5×10⁻⁶/℃
Electrical Resistivity :
1000~2000Ω·mm²/m
Model Number :
Customizable
Brand Name :
KEGU
Place of Origin :
China
Price :
200-500 yuan/kg
Payment Terms :
L/C,D/A,D/P,T/T,,
Supply Ability :
2,000 pcs/month
Packaging Details :
Strong wooden box for Global shipping
Description
Silicon Rod SiC Heating Elements For Laboratory And Industrial Furnace
The 1500°C ED Type SiC Heating Element is a non-metallic high-temperature electric heating solution manufactured from selected high-purity green silicon carbide. Through processing at 2400°C, the material forms silicon crystal blanks ideal for furnace applications operating between 600°C and 1600°C. These elements are widely utilized in glass, chemical, and electronic material heating applications.
Product Specifications
Diameter Range: 8mm to 60mm
Length Range: 300mm to 450mm
Available Configurations: Equal diameter, groove-shaped, U-shaped, gun-shaped
Key Features & Advantages
  • Maximum working temperature of 1600°C
  • Rapid temperature rise with stable performance and extended service life
  • Noise-free operation with zero air pollution
  • Easy installation and minimal maintenance requirements
