High Brightness LCD Battery Charger Discharger Single Real Time Data Memory
High Brightness LCD Battery Charger Discharger Single Real Time Data Memory
High Brightness LCD Battery Charger Discharger Single Real Time Data Memory
High Brightness LCD Battery Charger Discharger Single Real Time Data Memory
Specifications
Brand Name :
Huaying
Model Number :
HYBT-701
Certification :
ISO
Place of Origin :
Wuhan Hubei China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T L/C
Supply Ability :
200 sets per month
Delivery Time :
7 Working Days
Packaging Details :
Wooden Case
Application :
battery activation,check discharge,charge
Data display :
charge current/battery charged capacity/battery voltage/charge time and etc
Large data memory :
Save 10 groups of activation data,10 groups of check discharge test data,10 groups of charge test data
Communication :
RS232 port and USB
Carry method :
Portable type ,move with roller wheel
Display mode :
LCD with High-brightness
Description

High Brightness LCD Battery Charger Discharger Single Real Time Data Memory

Introduction

It is a compact unit for daily maintenance of single cell, especially for old cells. It plays three roles: charger, discharger and activator, which will facilitate your maintenance for batteries. These three functions could be used individually or comprehensively.

Features

1/. Portable device

2/. User friendly

3/. Well designed and easy-to-do

4/. Powerful functions with 3 in 1 (discharger, charger and activator)

5/. Accurate data results and vivid waveforms

6/. Integrated functions for displaying, controlling and loading

7/. Password management in key parts

8/. Safety circuits to prevent damage to cells

9/. Longtime monitoring of cell condition

10/. Direct USB drive for data transferring

11/. Convenient analysis software in PC

12/. Software system updatable

Technical index

Measurement type of cell voltage 2V/6V/12V;
Measurement range of cell voltage 2V:0～3V; 6V: 4-8V; 12V:4-15V
Resolution of cell voltage 2V: 0.001V,6V: 0.01V, 12V:0.01V
Voltage testing accuracy 0.5%
Working range of charge and discharge current 2A～100A
Control accuracy of charge and discharge current 0.1A
Current testing accuracy 1%
Battery capacity check range 2V:20-1000Ah; 6V:20-200Ah:12V:20-300Ah;
Working voltage AC 220±15%
Communication mode RS232 communication and USB communication
Cooling mode Refrigeration by blasting
Working environment Temperature: 0℃～40℃ Humidity: 20%～80%RH
Storage condition -20℃～70℃ package and storage
Display mode LCD with High-brightness
External dimensions(w×h×l) 450mm×190mm×585mm
Weight 11kg
Carry method Portable type ,move with roller wheel

High Brightness LCD Battery Charger Discharger Single Real Time Data Memory
