Specifications
Brand Name :
Pullner
Model Number :
PLZ-PPL
Certification :
ISO19001, ISO14001, ISO45001
Place of Origin :
Shanghai,China
MOQ :
10
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1000+PC+per week
Delivery Time :
7-10 work days
Packaging Details :
Individual packaged in carton box after poly bag.
Description

Basic Info.

Model NO.
PPL series
Type
PP Filter
Filter Connector
Fin
Filtration Grade
PRE Filter
Transport Package
Carton
Specification
20''
Trademark
PULLNER
Origin
China
HS Code
8421999090
Production Capacity
1000PCS Per Day

Packaging & Delivery

Package Size
62.50cm * 40.50cm * 41.00cm
Package Gross Weight
17.000kg

Product Description


PP Pleated OD 68.5mm Water Pleated Filter Cartridge

Application
Food and beverage: beer, wine filtration; juice and soda Filtration, oral liquid filtration; Additives, oil filtration
Water treatment: urban water supply, industrial water filtration; Power plant condensate filtration
Metal processing: cutting fluid and coolant filtration; Lubricating oil filtration
20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction
Specification
Item
Technical Parameters
Filter medium
Polypropylene (PP)
Support/Drainage
Polypropylene (PP)
Core/Cage/End Cap
Polypropylene (PP)
Outside diameter
2.7" (68.5mm)
Length
10", 20", 30", 40"
Micron
0.1um, 0.22um, 0.45um, 1um, 2um, 3um, 5um, 10um, 20um, 30um, 60um
Filtration area
0.4-0.7m²
Max. operating differential pressure
ΔP≤0.35MPa at25℃
Max. operating differential pressure (reverse direction)
ΔP≤0.28MPa at60℃
Sterilization temperature
30 minute cycles @121℃
Max. operating pressure
4bar/21℃
2.4bar/80℃
Material Constructions
Filter media
Polypropylene (PP)
Support/Drainage
Polypropylene (PP)
Cage/Core/End caps
Polypropylene (PP)
Seal material
Silicone, NBR, Vit, EPDM
Company profile
20'' Nominal Rating Polypropylene Filter Cartridge for Food and Beverage Filtration with PP Material Construction
Shanghai Pullner Filtration Technology Co.,LTD.
Since: 2013
Specialty: PP pleated filter cartridges, melt-blown filter cartridges, string wound filter cartridges, stainless steel filter cartridges, etc.

China domestic office: Beijing, Guangzhou, Fujian, Sichuan, Guangxi, Yunnan, Xinjiang, Inner Mongolia, Shaanxi, Northeast China.
Global branch and office: UAE (Dubai), Malaysia (Kuala Lumpur), Russia
FAQ
Q1: What is the brand name of this product?
A: The brand name is PULLNER.

Q2: What is the model number of this product?
A: The model number is PLZ.

Q:3 Where is this product manufactured?
A: This product is made in China.

Q4: What is the main function of this product?
A: The main function of this product is to filter beverages.

Q5: What is the recommended usage time for this product?
A: The recommended usage time for this product is 6-12 months.
