Specifications
Brand Name :
OEM/Customized
Model Number :
ZH070P4001-01
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Display Size :
7 Inch AMOLED
Resolution :
1080x1920
Luminance :
800 cd/㎡ (Typ.)
Touch Screem :
ONCELL
Outline Dimensions :
89.13(W)x160.9(H)x0.455 (T) mm
Operating Temperature :
-20 °C-60°C
Description

AMOLED Display Module 7-inch 1080×1920 Brightness 800nits with Touch Panel

The ZH070P4001-01 7-inch OLED display is engineered for premium visual clarity and performance, making it the ideal choice for a wide variety of industrial, commercial, and embedded applications. With an impressive 1080x1920 resolution, this OLED display offers vibrant colors, deep blacks, and exceptional contrast ratios, providing superior image quality compared to traditional LCDs.

interface, this display supports high-speed data transfer, ensuring fluid performance for dynamic content. With a maximum frame rate of 165Hz, it is perfect for applications that require high refresh rates such as interactive displays, medical devices, and gaming systems.

The ZH070P4001-01 features an ONCELL touch screen with the FT3518U touch IC, providing enhanced touch sensitivity and durability for interactive applications. Whether used for industrial automation, medical diagnostics, or consumer electronics, this display guarantees exceptional performance and reliability

Applications of ZH070P4001-01 OLED Display
The ZH070P4001-01 OLED display is designed for a wide array of high-performance applications, including:

Industrial Control Panels: Ideal for manufacturing and factory automation systems requiring high-resolution displays with reliable performance.

Medical Devices: Excellent for portable medical equipment and diagnostic systems where clarity and precision are critical.

Embedded Systems: Perfect for use in embedded systems, including handheld devices, tablets, and kiosks.

Consumer Electronics: Used in high-end consumer products like smart devices, wearables, and high-quality gaming systems.

Automotive Displays: Suitable for automotive infotainment systems and dashboards, offering superior visibility and contrast under varying lighting conditions.

Product Specification

item ZH070P4001-01
Screen Size 7 Inch OLED
Resolution 1080x1920
Brightness 800 cd/m²(Typ.)
Interface MIPI 4Lan
Driver IC VTDR6130
Frame Rate Support Max 165Hz
Active Aera 87.1344(W) x 154.90(H) mm
Outline Dimension 89.13(W)x160.9(H)x0.455 (T) mm
Operating Temperature -20℃~+70℃
Storage Temperature -40℃~+80℃
Touch Screen ONCELL
Touch IC FT3518U

Product Drawing

7 Inch FHD AMOLED Display Module 1080x1920 Brightness 800nits With Touch Panel

7 Inch FHD AMOLED Display Module 1080x1920 Brightness 800nits With Touch Panel

Why Choose ZhanHui TFT LCD Screen?

  • Having been dedicated to industrial vehicle-mounted LCD module applications for 10 years
  • A powerful engineering support team offers a one-stop integrated solution
  • Flexible and efficient customization capabilities, with rapid response to demands
  • Strict quality control system (such as through IATF 16949, ISO 9001)
  • Global logistics and localized service support
  • Highly competitive cost-effectiveness

FQA

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.

2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.

3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display

5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!

Call to Action :

  • Upgrade your device visibility with this premium OLED Displays!

  • Request a Quote Today!

  • Download Full Datasheet (Link)

  • Contact Sales for Volume Pricing

  • Integrate Brilliance - Order Samples Now!
