Specifications
Brand Name :
OEM/Customized
Model Number :
ZH080PIDHF001-02A
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Size :
8.0 Inch
Resolution :
1920x1200
Brightness :
1000 cd/m² （Typ.）
Display type :
IPS, Normally Black
Outline Dimensions :
181.7 (W) x119.8 (H)x 5.5 (T) mm
Operating Temperature :
-20℃~+70℃
Description

8.0-Inch Full HD TFT LCD Display Module 1000nits High Brightness Sunlight-Readable

The ZH080PIDHF001-02A is an 8.0-inch High Brightness LCD Display designed for industrial, commercial and outdoor applications, providing crisp Full HD resolution (1920×1200 ) and vivid color reproduction even in harsh outdoor environments. The display is equipped with an LVDS 2-port interface and a wide viewing angle, ensuring a smooth visual experience in any direction.

High Brightness for Challenging Environments: The 1000 cd/m² brightness ensures that the display remains visible, even in environments with high ambient light or outdoor exposure, making it perfect for digital signage and industrial control systems.

Wide Temperature Range: The -30℃ to +85℃ operating temperature makes the ZH080PIDHF001-02A suitable for extreme environments, such as manufacturing floors, warehouses, and outdoor applications.

Interactive Capabilities: The optional touch panel allows for interactive features, enhancing customer experience in POS terminals, self-service kiosks, and smart devices.

Energy Efficient: Equipped with a white LED backlight, this High Brightness LCD Display is not only bright but also energy-efficient, lowering the overall operational costs over time.

This 8 inch High Brightness LCD Display of Application Scenarios:

Outdoor Photography Monitors

Medical & Laboratory Equipment

Smart Industrial Control Panels

Military & Aerospace Interfaces

Vehicle-Mounted Displays

Ruggedized Tablets & HMI Devices

Company's focus on the core

  • Industrial-Grade TFT/OLED Displays (0.96" to 32")
  • Brightness up to 1000cd/m² ~2500cd/m² Sunlight Visibility
  • Wide Temperature -30℃ to +80℃ ,-40℃ to +95℃
  • Touch Solutions: Resistive/Capacitive/Cover Glass
  • TN/IPS Panels | Custom Backlight Systems

Product Specification

item ZH080PIDHF001-02A
Screen Size 8.0 Inch
Resolution 1920x1200
Brightness 1000 cd/m²(Typ.)
Display Mode IPS, Normally Black
Interface 2-port LVDS(8bit)
Active Aera 172.224(W) x107.640(H) mm
Outline Dimension 181.7 (W) x119.8 (H)x 5.5 (T) mm
Backlight white LED,360mA 18v
Operating Temperature -30℃~+85℃
Storage Temperature -30℃~+85℃
Touch Panel Optional Touch Panel

Product Drawing

8 Inch Full HD TFT LCD Display Module 1000nits High Brightness Sunlight Readable

8 Inch Full HD TFT LCD Display Module 1000nits High Brightness Sunlight Readable

Why Choose ZhanHui TFT LCD Screen?

  • Having been dedicated to industrial vehicle-mounted LCD module applications for 10 years
  • A powerful engineering support team offers a one-stop integrated solution
  • Flexible and efficient customization capabilities, with rapid response to demands
  • Strict quality control system (such as through IATF 16949, ISO 9001)
  • Global logistics and localized service support
  • Highly competitive cost-effectiveness

FQA

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.

2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.

3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display

5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!

Call to Action :

  • Upgrade your device visibility with this premium High Brightness LCD Display!

  • Request a Quote Today!

  • Download Full Datasheet (Link)

  • Contact Sales for Volume Pricing

  • Order Samples Now!
