Specifications
Brand Name :
Anycut
Model Number :
ZKSVD370DW_RL
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1 piece
Price :
￥$1145~1622/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/3days;5~30pieces/15 days;31~100pieces/20days
Delivery Time :
20~30 work days
Packaging Details :
L890mm*W590mm*H570mm
Max force :
3000g
Connect or interface :
USB cable/Udisk/web cable/WIFI
Suitable cutting material :
Self-adhesive sticker/coated paper/PVC
Positioning mode :
Qr code/Dot/Right angle
Support software :
CDR/AI/PS/Contour software/Signmaster(optional）
suitable cutting material :
self-adhesive sticker/coated/PVC
Max material thickness :
600gsm
motor :
high speed servo motor
Max cutting speed :
1600mm/s
Control panel :
4.3 inch touch screen
Description

Super Force SVD370DW_RL Double Heads A3/A4 Sheet Self-adhesive Sticker Wheel Indentation Cutting Machine



1. Efficient & Versatile Cutting:

Achieves full cut and half cut in one pass, with a high cutting speed of 1600mm/s, enabling quick processing of a wide range of materials including self-adhesive labels, coated paper, PVC, PET, and specialty papers.


2. User-Friendly Operation:

Equipped with a 4.3-inch touch screen control panel and high-speed servo motor, ensuring smooth, responsive performance. The Roland blade type ensures clean, precise cuts every time.


3. Flexible Connectivity:

Offers multiple connection options including USB, U-disk, wired network, and WiFi, allowing seamless integration into any workflow and easy operation from various devices.


4. Robust & Reliable Build:

Boasts a powerful 3000g max force, capable of handling materials up to 600gsm thickness, with a durable design for long-term, heavy-duty use.


5. Wide Compatibility:

Supports CDR/AI/PS/Contour software and Signmaster (optional), and works with all versions of the Windows operating system, making it adaptable to diverse design and production environments.




MODEL ZKSVD370DW_RL
Max. media width 370mm
Max. cutting width 340mm
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor High speed servo motor
Positoning mode Qr code/Dot/Right angle
Number of heads 2
Blade type Rowland blade
Packing size L 890mm*W 580mm*H 570mm
Machine size L 768mm*W 455mm*H 336mm
Gross/Net weight 63kgs/46kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 600gsm
Max. cutting speed 1600mm/s
Max.force 3000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Suitable cutting material Self-adhesive sticker/coated paper/PVC
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory 1G
Support system All versions of windows
