Specifications
Brand Name :
Anycut
Model Number :
ZK1750-SF
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
MOQ :
1 Piece
Price :
$1070~1398/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/ 2days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20-30 work days
Packaging Details :
L2110mm*W400mm*H440mm
Control panel :
5.0 inch LCD touch screen
support sofatware :
CDR/AI/PS/Contour software/signmaster(optional)
Cutting length :
Unlimited
Main board :
ARM smart dual-core chip
Auto contour cut :
Camera
Max.media width :
1600mm
Max.cutting speed :
1200mm/s
Max.force :
2000g
connect or interface :
USB cable/Udisk/web cable/WIFI(optional)
Motor :
Servo drive+Servo motor
Description

ZK1750-SF Quiet And High Speed Servo Motor Cutting Plottr With CCD Camera Positioning



The ZK1750-SF is a high-performance cutting plotter designed for precision and efficiency, equipped with camera automatic positioning technology to ensure accurate contour cutting of complex graphics and stickers. It delivers an industry-leading 2000g cutting force, easily handling tough materials like PVC adhesive backing, magnetic sheets, and light box films.

Powered by a quiet, high-speed servo motor, it achieves a maximum cutting speed of 1200mm/s while maintaining ±0.01mm cutting accuracy and 0.082mm repeatability, guaranteeing clean, precise results every time.


Whether for sticker production, heat transfer printing, or vehicle graphics, the ZK1750-SF combines robust construction, advanced features, and versatile material handling to meet the demands of high-volume, professional cutting tasks.



MODEL ZK1750-SF
Max. media width 1750mm
Max. cutting width 1600mm
Packing size L 2110mm*W 400mm*H 440mm
Machine size L 2000mm*W 600mm*H 1100mm
Gross/Net weight 55kgs/49kgs
Control panel 5.0inch LCD touch screen
Motor Servo drive + Servo motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 1200mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 1
Number of Y motor 1
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/web cable/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows
