1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
Specifications
Brand Name :
Anycut
Model Number :
ZK1750-SF
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
MOQ :
1 Piece
Price :
$1070~1398/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/ 2days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20-30 work days
Packaging Details :
L2110mm*W400mm*H440mm
Max.media width :
1600mm
Control panel :
5.0 inch LCD touch screen
Motor :
Servo drive+Servo motor
Cutting length :
Unlimited
Max.cutting speed :
1200mm/s
Max.force :
2000g
Main board :
ARM smart dual-core chip
Auto contour cut :
Camera
connect or interface :
USB cable/Udisk/web cable/WIFI(optional)
support sofatware :
CDR/AI/PS/Contour software/signmaster(optional)
Description

1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen



The ZK1750-SF is a high-performance cutting plotter designed for precision and efficiency in sign making, sticker production, and graphic applications.

Equipped with a 2000g super cutting force, it effortlessly handles tough materials like PVC, reflective vinyl, and white ink stickers, while its servo drive motor ensures quiet, high-speed operation with a max cutting speed of 1200mm/s.

For seamless connectivity, it supports USB, U-disk, wired network, and optional WiFi, allowing flexible data transfer. The 5.0-inch LCD touch screen offers intuitive operation.With a max media width of 1750mm and unlimited cutting length, it meets the demands of large-format production.

This floor-standing plotter is compatible with all Windows systems and popular design software (CDR, AI, PS, Contour software, Signmaster optional), making it a versatile solution for professional sign shops and print businesses.



MODEL ZK1750-SF
Max. media width 1750mm
Max. cutting width 1600mm
Packing size L2110mm*W400mm*H440mm
Machine size L2000mm*W600mm*H1100mm
Gross/Net weight 55kgs/49kgs
Control panel 5.0inch LCD touch screen
Motor Servo drive + Servo motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 1200mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 1
Number of Y motor 1
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/web cable/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows



1750mm Large Format Super Force High Speed Die Cutting Machine with 5.0 Inch Touch Screen
