Specifications
Brand Name :
Anycut
Model Number :
ZKSV370
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1 piece
Price :
$1356~1542/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L890mm*W580mm*H570mm
Auto contour cut :
Camera(automatically contour cutting)
support software :
CDR/AI/PS/Contour software/Signmaster(optional)
suitable cutting material :
self-adhesive sticker/coated paper/PVC
max force :
2000g
connect or interface :
USB cable/Udisk/web cable/WIFI
max thickness material :
450gsm
max cutting width :
340mm
packing size :
L890mm*W580mm*H570mm
packing details :
wooden case
positioning mode :
Qr code/Dot/Right angle
Description

ZKSV370 1600mm/s High Speed Servo Motor Label Cutting Machine With Single Head


  • High-Speed Servo Motor: Delivers ultra-fast cutting up to 1600mm/s with precision control.
  • Auto Contour Cutting: Built-in camera automatically recognizes QR codes/dots for seamless kiss & full cut.
  • Versatile Connectivity: USB, U-disk, Ethernet, and WIFI for flexible workflow integration.
  • Wide Material Compatibility: Cuts self-adhesive sticker, coated paper, PVC, and more up to 450gsm.
  • User-Friendly Design: 4.3-inch touch screen, Roland blade, and compatibility with all Windows versions & design software (CDR/AI/PS).
  • Compact & Powerful: 370mm max media width, ±0.01mm cutting accuracy, and <150W power consumption.


ZKSV370 1600mm/s High Speed Servo Motor Label Cutting Machine With Single Head



ZKSV370 1600mm/s High Speed Servo Motor Label Cutting Machine With Single Head



MODEL ZKSV370
Max. media width 370mm
Max. cutting width 360mm
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor High speed servo motor
Positoning mode Qr code/Dot/Right angle
Number of heads 1
Blade type Rowland blade
Packing size L 890mm*W 580mm*H 570mm
Machine size L 768mm*W 455mm*H 336mm
Gross/Net weight 47kgs/42kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1600mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Suitable cutting material Self-adhesive sticker/coated paper/PVC
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory 1G
Support system All versions of windows
