Specifications
Brand Name :
Anycut
Model Number :
ZKSS600
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1 piece
Price :
$230~257/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L1000mm*W285mm*H310mm
max cutiing width :
632mm
max contour cutting width :
590mm
max force :
800g
cutting precision :
+/-0.01mm
auto contour cut :
camera
max moving speed :
700mm/s
max cutting speed :
600mm/s
connect or interface :
USB flash/WIFI/USB cable
control panel :
pure capacitive LCD touch screen
motor :
stepper
Description

Economic ZKSS600 CCD Camera Automatic Edge Patrol Plotter 700mm/s High Precision Die Cutting Machine



  • Smart & Intuitive Control: 5-inch LCD display with a large-screen central console for easy operation, supporting multi-language switching.
  • Advanced Connectivity: Seamless WiFi, USB flash drive, and USB cable connections for flexible workflow.
  • Precision Cutting Performance: Stepper motor drive, ±0.01mm cutting precision, and up to 700mm/s moving speed for efficient, high-quality results.
  • Powerful & Versatile: Max 1000g force, compatible with various special materials, plus hidden carriages and integrated pressure rollers for stable, reliable performance.
  • Auto Contour Cutting: Built-in CCD camera for automatic edge patrol, enabling accurate contour cutting up to 590mm width.
  • Compact & Efficient: 669mm max media width, <48W low power consumption, and a robust 15.3kg structure for professional use.


MODEL ZKSS600
Max. media width 669mm
Max. cutting width 632mm
Max auto contour cutting width 590mm
Packing size Outer carton 1000*285*310mm
Packing Gross weight 15.3kg
Motor Stepper
Cutting precision +/- 0.01mm
Repeat precision YES
Max. cutting speed 700mm/s
Max.force 800g
Connect or interface USB flash/WIFI/USB cable
Power <48W
Max moving speed 700mm/s
Power supply,V/Hz 100v-240VAC50/60HZ,24V/2,75A
Processor Memory 1G
Support system All versions of windows
