Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-Stable Adsorption Intelligent Positioning
Specifications
Brand Name :
Anycut
Model Number :
ANYCUT-ZKF3550
MOQ :
1piece
Price :
$1240~1522/piece
Payment Terms :
T/T,Western Union
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20-30 work days
Packaging Details :
L1430mm*W755mm*H480mm
Max.cutting width :
350mm*500mm
Auto contour cut :
Camera
Control panel :
5.0 inch touch screen
Positioning mode :
L-corner/dot/QR code recognition/support multi-filr mixing
Motor :
DC servo motor
Blade type :
Cutting knife,indentation knife,painbrush
Max.material thickness :
450gsm
Max.cutting speed :
1200mm/s
Description

Anycut Flatbed Die Cutting Plotter Machine Desktop Vacuum-stable Adsorption Intelligent Positioning



The ANYCUT-ZKF3550 is an intelligent flatbed cutter designed specifically for desktop-level fine processing. Its compact desktop body is suitable for small workshops and studio scenarios, while integrating three core advantages: First, vacuum adsorption technology paired with precise camera positioning can firmly fix thin and soft materials (such as self-adhesive and specialty paper).Second, the dual-head cutting system supports composite processes (cutting, creasing, brush marking, etc.), adapting to thicker and harder diverse materials, covering processing needs such as personalized business cards, cardboard tags, and cartons.


With a cutting speed of 1200mm/s, it balances the efficiency of small-batch orders; meanwhile.From the cutting of personalized materials in cultural and creative studios to the small-batch label processing in small packaging factories, the ANYCUT-ZKF3550, with its differentiated advantages of "desktop portability + vacuum stable adsorption + intelligent positioning precision cutting", serves as a high-efficiency tool for small-scenario production.



MODEL ANYCUT-ZKF3550
Maximum material size 480mm*675mm
Maximum cutting size 350mm*500mm
Auto contour cut Camera
Control panel 5.0 inch touch screen
Motor DC servo motor
Positioning mode L-corner/dot/QR code recognition/support multi-file mixing
Number of heads 2
Blade type Cutting knife,indentation knife,painbrush
Packing size L1430mm*W755mm*H480mm
Machine size L940mm*W690mm*H290mm
Gross/Net weight 35kgs
Cutting accuracy +/-0.01mm
Repeatability +/-0.01mm
Max.material thickness 450gsm
Max cutting speed 1200mm/s
Max.force 2000g
Connect or interface WIFI/USB/network port
Power Host:120W Fan:1000w
Woking environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Suitable cutting material Cardboard/hot stamping film/self-adhesive/kraft paper/PVC/PET
Support software CDR/AI/PS/Contour software/Signmaster(Optional)
Memory 1G
Support system All version of windows
