Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery
Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery
Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery
Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery
Specifications
Brand Name :
HEYI
Model Number :
2.56KWH
Certification :
UN38.3 , MSDS , IS9001
Place of Origin :
CHINA
MOQ :
1
Price :
USD500~700
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
1 GWH
Delivery Time :
10 working days
Packaging Details :
wooden case
Nominal Voltage :
24V
Capacity :
2.56 kWh
Logo :
Can be customized
Battery Cell :
LifePO4 3.2V
Temperature Range :
Wide
Protocol :
RS485 and RS232
Protection :
Built-in BMS
Standard Charge Current :
Constant Current 1C
Design :
Rack mounted
Cell Type :
Prismatic Cell
The Discharge Rate :
1C
Keywords :
Battery Lithium Lifepo4
Chemistry :
LiFePO4
Storage Type :
Normal
Description

Expandable 24v 100ah Rack Mounted Lithium Battery Wholesaler

Looking for a reliable 24V 100Ah rack-mounted lithium battery wholesaler? Our expandable 24V LiFePO₄ battery module is engineered for high performance, long life, and safe operation—perfect for solar energy storage, telecom backup, and commercial power systems.

Built with brand-new Grade A lithium iron phosphate (LiFePO₄) cells, this battery features a smart Battery Management System (BMS) that provides multi-level protection and ensures consistent performance over thousands of cycles.

This modular battery supports parallel expansion, making it easy to scale your system from small residential setups to large commercial or industrial applications. Compatible with 24V and 48V configurations, it integrates seamlessly with off-grid and hybrid inverters, MPPT solar charge controllers, and existing battery systems.

Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery

Specification :

Model SM24-100 SM24-150 SM24-200 SM48-50 SM48-100 SM48-150
Energy 2560Wh 3840Wh 5120Wh 2400Wh 4800Wh 7200Wh
Nominal Voltage (V) 25.6V 25.6V 25.6V 48V 48V 48v
Rated Capacity (Ah) 100Ah 150Ah 200Ah 50Ah 100Ah 150Ah
Chemistry Lithium Iron Phosphate (LiFePo4)
Design Life More than 10 years
Cycle Life More than 3500 cycles at 80% DOD.
Communication Protocol CAN , RS485 , RS232
Display LED Display Optional
Internal Impedance 50 mΩ
Max. Charging Current 50A 80A 100A 50A 100A 100A
Max. Continue Discharging Current 80A 100A 100A 70A 100A 100A
Battery Dimensions (MM) 438*375*133mm 442*400*177mm 442*400*177mm 438*375*133mm 442*400*177mm 442*400*177mm
Weight Approx: 40kg Approx: 58kg Approx: 70kg Approx: 40kg Approx: 70kg Approx: 80kg
Battery Protection Over-charge &Over discharge protection , over current protection ,over temperature production , short-circuit products , cells balance
Outer Package Material Black Power Coated steel case (battery rack or cabinet is optional)
Operating Temperature Charging: 0 to +50℃ Discharging: -20 to +60℃ Storage: -20 to +60℃

Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery

Features :

  • Wholesale-ready 24V 100Ah LiFePO₄ rack-mounted battery
  • High safety, long cycle life (6000+ cycles at 80% DOD)
  • Advanced BMS for full protection and stable output
  • Easy to install, modular, and parallel expandable
  • Compatible with leading inverter and solar controller brands
  • Ideal for home solar, telecom stations, off-grid cabins, and backup systems
  • Expandable 24v100ah Rack Mount Solar Battery Household Lithium Battery
  • Applications :

  • Home solar storage systems

  • Wind-solar hybrid systems

  • Telecom base stations

  • Emergency backup power

  • Stationary energy storage projects
