Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
Specifications
Brand Name :
HEYI
Model Number :
36V20Ah
Certification :
UN38.3 . MSDS
Place of Origin :
China
MOQ :
100
Price :
USD69~99
Payment Terms :
,T/T,Western Union,MoneyGram
Supply Ability :
1 GWH
Delivery Time :
10 working days
Packaging Details :
Carton
Chemistry :
Lithium Iron Phosphate (LiFePO4)
Weight :
Approximately 20 lbs
Voltage :
48V
Capacity :
15Ah
Dimensions :
367.5x95x89 MM
Cycle Life :
6000 cycles
Discharging Current :
15A
Application :
E-bike
Operating Temperature :
-20°C to 60°C
Warranty :
5 years
Description

48v 30ah lithium ion battery electric bike batteries

Our lithium battery series (24V, 36V, 52V) offers high-performance power for electric bikes and scooters, featuring intelligent BMS technology for multi-layer protection—covering current, voltage, temperature, and short-circuit issues. Housed in waterproof ABS casing and made with reliable Grade A cells, these batteries offer long service life—over 5000 cycles. Extras like USB charging, battery level indicators, and secure locking make them a smart and safe choice for personal electric transport.

Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles

Specification :

Model 36V/15Ah 36V/20Ah 48V/15Ah 48V/20Ah 52V/15Ah 52V/20Ah
Nominal Voltage (V) 36V 36V 48V 48V 52V 52V
Nominal Capacity (Ah) 15Ah 20Ah 15Ah 20Ah 15Ah 20Ah
Energy 540Wh 720Wh 720Wh 960Wh 780Wh 1040Wh
Battery Dimensions (MM) 367.5x95x89 367.5x95x122 367.5x95x89 367.5x95x122 customized customized
Layout/Terminals Anderson Anderson Anderson Anderson Anderson Anderson
Case /Packing Aluminium Aluminium Aluminium Aluminium Metal Case Metal Case
LED display Optional Optional Optional Optional Optional Optional
Blue tooth Optional Optional Optional Optional Optional Optional
Comms. NO NO NO NO Optional Optional
Charging Voltage 54.6V 71.4V 71.4V 71.4V 84V 84V
Optimum charge current 3A~5A 3A~5A 3A~5A 3A~5A 3A~5A 3A~5A
Max.Continuous discharge current 50A 80A 50A 80A 50A 80A
Peak discharge current 100A 100A 100A 150A 150A 150A
BMS Charge Voltage Cut-Off 55.25V (4.25 ±0.025 vpc) (1.1 ±0.4 s) 72.25V (4.25 ±0.025 vpc) (1.1 ±0.4 s) 85.0V (4.25 ±0.025 vpc) (1.1 ±0.4 s)
BMS Discharge Voltage Cut-Off 36.4V (2.8 ±0.08 vpc) (100ms) 47.6V (2.8 ±0.08 vpc) (100ms) 56V (2.8 ±0.08 vpc) (100ms)
Chemistry Lithium-ion (NCM)
Cycle life >2000cycle at 100% Depth of Discharge (DoD), up to 5000 cycles at 80% DoD
Operating temperatures Standard 0℃~60℃
Discharge -30℃~75℃
Storage -20℃~45℃
Storage performance Capacity can be kept ≥ 80% in storage for 12months
Warranty 3 years

Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles

Features :

Comprehensive Safety: Multi-protection BMS safeguards against all electrical hazards including overvoltage, overcurrent, and thermal extremes while ensuring stable power delivery.
User-Friendly Features: Portable design with battery status indicator, security lock, and built-in USB power bank functionality for on-the-go charging.
Superior Performance: Military-grade waterproof casing protects high-density cells that provide twice the range of standard batteries and 5000+ reliable cycles.
Wide Compatibility: Perfect for electric motorcycles, city bikes, balance scooters and more - confirm your vehicle's voltage requirements for optimal performance.

Applications :

E-Bikes / Scooters / Wheelchairs / Tricycle / Golf Cart / Electric Vehicles/Boat

Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles

WHY CHOOSE US

Grade A Cells

The heart of our batteries features brand-new Grade A cylindrical cells, delivering superior energy density and cycle life compared to standard cells.

Built-in BMS

Our intelligent Battery Management System (BMS) provides:

  • Protection against: Over-charging, over-discharge, over-current, and short circuits

  • Low-voltage cutoff: Automatic power shutdown for safety

  • Real-time voltage/temperature monitoring

Intelligent BMS 48v 30ah Lithium Ion Battery Lifepo4 Electric Bike Battery 6000cycles
