5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
Specifications
Brand Name :
HEYI
Model Number :
24V300AH
Certification :
UN38.3 MSDS
Place of Origin :
CHIAN
MOQ :
10
Price :
USD79~399
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
1 GWH
Delivery Time :
10 working days
Packaging Details :
Cartons / Wooden Case
Voltage :
24V
Capacity :
300Ah
Chemistry :
LiFePo4
Self-Discharge Rate :
less than 1% per month
Warranty :
5 years
Operating Temperature :
-20°C to 60°C
Cycle Life :
5000 cycles
Description

24V Lithium Battery Pack for Solar Energy Storage and Backup Power

Our 12V/24V lithium batteries are crafted with premium-grade LiFePO₄ cells, offering a lightweight, maintenance-free power solution. Designed for seamless lead-acid battery replacement, they bring better energy output and improved longevity to applications such as solar power, marine systems, and mobile homes.

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery

Specification :

Specifications

Model

SP12-100

SP12-150

SP12-200

SP12-300

SP24-100

SP24-150

SP48-50

Nominal Voltage (V)

12.8V

12.8V

12.8V

12.8V

25.6V

25.6V

51.2V

Nominal Capacity (Ah)

100Ah

150Ah

200Ah

300Ah

100Ah

150Ah

50Ah

Energy

1280Wh

1920Wh

2560Wh

3840Wh

2560Wh

3840Wh

2560Wh

Chemistry

Lithium Iron Phosphate (LiFePo4)

Battery Dimensions (MM)

330x173x220

400x175x240

510x210x208

525x240x220

510x210x208

525x240x220

510x210x208

Net Weight

13(Kg)

19(Kg)

29(Kg)

35(Kg)

32(Kg)

35(Kg)

28(Kg)

Layout/Terminals

M8

M8

M8

M8

M8

M8

M8

Case /Packing

ABS Case

LED display

Optional

Optional

Optional

Optional

Optional

Optional

Optional

Bluetooth

Optional

Optional

Optional

Optional

Optional

Optional

Optional

Comms.

Optional

Optional

Optional

Optional

NO

NO

NO

Cycle life

>3000cycle at 100% Depth of Discharge (DoD), up to 6000 cycles at 80% DoD

Charge Method

CC/CV

Standard charge current

20A

30A

40A

60A

20A

30A

10A

Optimum charge current range

10A ~ 100A

10A~100A

10A ~ 150A

10A ~ 200A

10A ~ 100A

10A~100A

10A ~ 50A

Rapid charging

Max.

charge current 100A (1C) (Max Temperature

increase within 15°C)

Max.

charge current 100A(Max Temperature

increase within 15°C)

Max.

charge current 100A (Max Temperature

increase within 15°C)

Max.

charge current 100A (Max Temperature

increase within 15°C)

Max.

charge current 100A (1C) (Max Temperature

increase within 15°C)

Max.

charge current 100A (Max

Temperature

increase within 15°C)

Max.

charge current 50A (1C) (Max Temperature

increase within 15°C)

BMS Charge Voltage Cut-Off

15.0 V (3.75 ±0.025 vpc) (1 ±0.2 s)

30.0V (3.75 ±0.025 vpc) (1.1 ±0.4 s)

60.0V

(3.75 ±0.025 vpc) (1.1 ±0.4 s)

BMS Discharge Voltage Cut-Off

8.8 V (2.2 ±0.08 vpc) (20ms)

17.6V (2.2 ±0.08 vpc) (20ms)

35.2V

(2.2 ±0.08 vpc) (20ms)

Max.Continuous discharge current

100A

150A

200A

200A

100A

100A

50A

Peak discharge current

200A

300A

300A

300A

200A

200A

100A

Operating temperatures

Standard 0℃~60℃ / Discharge -30℃~75℃ / Storage -20℃~45℃

Storage performance

Capacity can be kept ≥ 80% in storage for 12months

Features :

✔ Ultra-Safe LiFePO4 Tech – Stable chemistry, no thermal runaway risk
✔ 10X Longer Life – 6,000+ cycles at 80% depth of discharge
✔ Drop-In Ready – Direct replacement for lead-acid, no wiring changes
✔ 50% Lighter – Easy to transport and install
✔ Rapid Recharge – No memory effect, faster than lead-acid
✔ Dual Voltage – Choose between 12V or 24V configurations
✔ Smart BMS Protection – Guards against overvoltage, overheating & shorts
✔ Green Energy – No hazardous metals, fully RoHS compliant

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery

Advantages :

Brand New Grade A Cells Only: We strictly use LFP prismatic battery cells for maximum quality and reliability.

Long Service Life: Up to 10 years design lifespan.

Maintenance-Free: No water refilling or corrosion issues as with traditional batteries.

Safe Transportation: Certified for air, sea, and ground shipment (UN38.3, MSDS).

Cost Effective: Despite the higher upfront cost compared to lead-acid, total ownership cost is much lower over tim

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery

Applications :

Electric vehicles (EV), electric scooters, electric bikes, and electric motorcycles

Marine: Custom marine lithium batteries and boat lithium batteries

Recreational Vehicles (RV batteries)

Solar Energy Storage Systems

Industrial Equipment: Forklifts, floor machines, and backup power systems

Start-Stop Systems: Suitable for auto start stop system and car start stop battery upgrades

Energy Storage Projects: Home, commercial, and off-grid applications

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery

Optional Features:

Bluetooth Monitoring

LCD Display

Heating Systems for Low-Temperature Environments

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
Why Choose Us ?

Professional Lithium Battery Manufacturer and Supplier

Only Sell Brand New Grade A Cells – no second-hand or downgraded cells

One-Stop Customization Service: Custom lithium battery packs, custom EV batteries, EV battery pack design, custom battery management solutions

Full Certifications: UN38.3, MSDS, CE, RoHS

Reliable Logistics: Secure packaging + global fast delivery

Competitive Price: Direct factory price for bulk orders, buy lithium battery solutions available

5000cycles 24v Lithium Ion Battery Pack Backup Power Energy Storage 24v Solar Battery
