SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
Specifications
Brand Name :
Herolaser
Model Number :
ML-2000
Certification :
CE, SGS
Place of Origin :
CHINA
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100 SETS PER MONTH
Delivery Time :
10-15DAYS
Packaging Details :
PLYWOOD BOX
Pulse width :
0.5~20ms
Condition :
New
Warranty :
2 Years
Single pulse energy :
80J
Wavelength :
1064nm
Cooling system :
Water Cooling
Welding depth :
0.1-3.5mm
Pulse frequency :
0~100Hz
Power supply :
220v/50Hz, 380V/50/60HZ
Laser type :
IPG/MAX/RECI
Keywords :
High-quality Laser Welding Machine
Description

Fifth Generation Fiber Laser Welding Machine 1000W 1500W 2000W

Machine Advantages
1. The welding seam is smooth and beautiful, which reduces the subsequent grinding process and saves time and cost.

2. Easy to operate, no need welding work license, unskilled operator can also weld products beautifully.

3. No effect for etch after welding, low oxidation rate, the color of the processing parts is intact.

4. The welding seam is smooth and beautiful, which reduces the subsequent grinding process and saves time and cost.

5. The welding speed is 2-10 times faster than the traditional welding speed. It can help you to save at least two welding operators a year.

6. Laser welding consumes less material and has a long-life, Safer and more environmentally friendly.

Applicable to material and fields
Ambry industry, railings of stairs and elevator , shelves, oven, stainless steel guardrail , distribution box, stainless steel home supplies etc.

SGS Approval 2000W Handheld Fiber Laser Welding Machine Time SavingSGS Approval 2000W Handheld Fiber Laser Welding Machine Time SavingSGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving

Specification

No. Item ML-WF-500W
1 Laser Power 500W
2 laser Wavelength 1070 NM
3 Fiber Cable length 10 meters
4 Cooling method Water
5 Voltage 220V
6 Power consumption 5KW
7 Frequency 50/60 HZ
8 Currency 23A
9 Laser gun Motor/lens wobble
10 Focus length 150mm
11 Cryogenic water flow 70 L/min
12 Room temperature water flow 15 L/min
13 water distilled water
14 laser Control method laser enable+ security lock+ metal switch/ safety clamp
15 Touch screen PLC screen and board
16 Wire feeder auto feeding and drawback

Material Protective gas Welding depth 500W 1000W 1500W 2000W
Aluminum N2 1.0 √ √ √
1.2 √ √ √
1.5 √ √
2.0 √ √
2.5 √
Stainless Steel Argon 0.5 √ √ √ √
0.8 √ √ √ √
1.0 √ √ √ √
1.2 √ √ √
1.5 √ √ √
2.0 √ √ √
2.5 √ √
3.0 √
Carbon steel CO2 0.5 √ √ √ √
0.8 √ √ √ √
1.0 √ √ √ √
1.2 √ √ √
1.5 √ √
2.0 √ √
2.5 √ √
galvanized sheet

Argon

 0.5 √ √ √ √
0.8 √ √ √ √
1.0 √ √ √
1.2 √ √ √
1.5 √ √
2.0 √
2.5 √

Packing Method
Plywood box packaging (packed in one plywood box)

SGS Approval 2000W Handheld Fiber Laser Welding Machine Time Saving
