High Efficiency Falling Film Evaporator Stainless Steel Customzied
High Efficiency Falling Film Evaporator Stainless Steel Customzied
Specifications
Certification :
ASME U/ISO9001/ ISO45001/ ISO14001/PED/CE/CRTU/DOSH
Material :
Stainless Steel
Model Number :
WFE/SPD/BEM/BES/AES/BEU/TFE
Style :
Steel Type
Payment Terms :
L/C,T/T
Price :
Negotiation
Usage :
Dairy, Food, Beverage, Pharmacy, Cosmetic, etc
Supply Ability :
6000sets/Year
MOQ :
1 Set
Delivery Time :
45-60 working days
Size :
Customzied
Place of Origin :
Jiangsu China
MOQ :
1set
Brand Name :
Yiteng
Application :
Thin Film Evaporator, TFE/pharmaceutical distillation equipment/API purification distillation
Packaging Details :
Steel saddle+LDPE foil+Tarpaulin/Wooden box
Description

High Efficiency Falling Film Evaporator

Product Description

The High-Efficiency Falling Film Evaporator is an advanced thermal separation system designed for the continuous concentration, evaporation, and recovery of heat-sensitive liquids. By allowing the liquid to flow as a thin film along the inner surface of heat transfer tubes, the equipment achieves rapid heat transfer, short residence time, and high evaporation efficiency while minimizing product degradation.

This evaporator is widely used in the chemical, pharmaceutical, food & beverage, biotechnology, environmental protection, and fine chemical industries for concentrating solutions, recovering solvents, and reducing energy consumption in production processes.

Type tubes Optional:
Plain/Finned/Threaded/Corrugated tube

Product parameter

Parameter Typical Value/Range Remarks
Evaporation Capacity 5～5500 kg/h Evaporation efficiency depends on material properties and heat transfer temperature difference
Operating Pressure 0.1~4.0 MPa (1~40 bar) up to 5 MPa
Operating Temperature 50-300°C High-temperature series with maximum operating temperature up to 350°C
Heat Transfer Area 0.1-100m² Custom designs available for the full range
Viscosity Range 1-100000cP Specialized wiper design required for high-viscosity materials

Why Partner With Us?

· 1:1 Drawing Optimization: Our engineering team reviews and optimizes your blueprints to reduce production costs.

· Reliable Lead Time: Streamlined manufacturing process ensures your project timeline is protected.

· Global Shipping Experience: Full support for sea freight, customs clearance, and documentation.

Let's discuss your next project!

Packaging & Shipping

High Efficiency Falling Film Evaporator Stainless Steel Customzied
