Euro 3 Dongfeng 20 Tons Towing Vehicle Recovery Tow Trucks Integrated
Euro 3 Dongfeng 20 Tons Towing Vehicle Recovery Tow Trucks Integrated
Euro 3 Dongfeng 20 Tons Towing Vehicle Recovery Tow Trucks Integrated
Euro 3 Dongfeng 20 Tons Towing Vehicle Recovery Tow Trucks Integrated
Euro 3 Dongfeng 20 Tons Towing Vehicle Recovery Tow Trucks Integrated
Euro 3 Dongfeng 20 Tons Towing Vehicle Recovery Tow Trucks Integrated
Specifications
Brand Name :
Dongfeng
Place of Origin :
Hubei, China
MOQ :
1
Supply Ability :
5 unit/month
Delivery Time :
85 days
Packaging Details :
Nude, covered with protection film
Product name :
Integrated Wrecker Truck
Condition :
New
Drive type :
6x4 driving
Main Winch :
10 tons, 2 pcs
Auxiliary Winch :
Optional
Underlift :
G70, 3 sections
Boom :
G70, 2 sections
Remote Control :
Wireless
Hydraulic :
DOT certified
Warranty :
3 Year
Description
6X4 EURO 3 DONGFENG 20 TONS TOWING VEHICLE RECOVERY TOW TRUCKS
Product Description

The heavy duty integrated series have different capacities from 20 tons to 50 tons.

BUILT FOR STRENGTH, RELIABILITY AND DURABILITY

The 20 tons integrated wrecker features a 44,500 lb. 2- or 3-stage wrecker boom, corrosion, resistant body and optional 3- or 4-stage underlifts – all designed with strength and performance in mind.

The truck brand options also available with ISUZU, Dongfeng, HOWO, JAC, FOTON, JMC, FAW, SHACMAN, IVECO, etc.

With Euro 2, Euro 3, Euro 5, Euro 6 emission.

With RHD, LHD.

With 4x2, 4x4, 6x4, 6x6, 8x4, 8x8.

Other special requirements you want.

Main Features
1. 10 Tons / 22,200 lbs. Planetary Winch, 2 Pcs. Total 20 Tons / 44,500 lbs.
2. 20 Tons / 44,500 lbs. Underlift Capacity, Tow Rate At Least 40 Tons / 88,800 lbs.
3. Optional Remote Control
4. Sides Tool Boxes
5. Optional Front Legs and Side Pullers
Truck Specs
6x4 Dongfeng Wrecker Truck
Overview
Name 6x4 Dongfeng Wrecker Truck
Dimension(LxWxH) 10580x2550x3120 (mm)
Total Mass 25000 Kg
Kerb Weight 20130 Kg
Passenger 3
The Parameters of Chassis 　
Manufacture/Model Dongfeng
Driving Type 6*4 left hand drive
Wheel Base 5600+1350 mm
Gearbox 12JSD180T, twelve speed forward and two reverse, manual
Tyre 315/80R22.5
The Number of Tyre 10+1(spare tyre)
Frame 300X90X8+5
AC Equipped
The Paremeters of Engine
Manufacturer/Model Cummins/ISLe375 30
Rated Power 375hp
Fuel Type Diesel oil
Displacement/Capacity 8900ml
Emission Standard Euro 3
Cylinder Straight/6/turbo charge/intercooling
Max. Torque 1550N.m
Velocity 2100rpm
Body Specs
25 Tons Wrecker Body Specs
No. Item Content Details Unit
1 Name 25 Tons Wrecker Body
2 Winches 2×10 Tons Main Winches

Side puller/ extra winch is optional,

extra USD2,500
3 Under lift Under lift G70 material, 3 stage
4 Boom Boom

G70 material, 2 stage,

hexagon
5 Legs Rear Hydraulic rear supporting legs

Front supporting legs are extra

USD3,500 or front outrigger

extra USD5,000.
6 Frame LED Lights Frame, full size
7 Toolbox On Both Sides

Carbon steel Q345R, with

stainless steel handles

Aluminum tool box optional,

extra USD5,000
8 Hook-Ups Air and Electrical Hook-Ups 12V or 24V
9 Control Remote Wireless Control Button remote control

Joystick type remote control,

English Display, optional,

extra USD2,000
Hand Manual Control

On Lift and Right Sides,

English

Indication
10 Hydraulic Parts Hydraulic Pump
Hydraulic Hose
Hydraulic Connector
Valves
Cylinders
11 Attachments 5 Sets of Forks 4 sets for axle, 1 set for suspension
U shape tyres holder 1 set
Safety Chains 2 pcs
12 Painting and Indication Electrophoresis Painting Primer and surface painting

All subframe with boom, under lift

and tool box EP painting optional,

extra USD2,500
Surface Painting Epoxy Resin
Indication English Indication and Marks
Packaging

Boxes and under lift protected

for the painting
Specifications
1 Underlift Retracted Lifting Capacity 25000 kg
Retracted Length 1746 mm
Extended Lifting Capacity 7310 kg
Extended Length 3110 mm
Undelift Tilt -10 °
Towing Capacity 50 ton
2 Boom Retracted Lifting Capacity (45°) 20 ton
Extended Lifting Capacity (45°) 12 ton
Max. Lifting Tilt 33 °
Max. Lifting Height 7022 mm
3 Main Winches Quantity 2 pcs
Pulling Power 10 ton
Type Planetary
Steel Wire Length 45 m
Steel Wire Diameter 18 mm
