3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting
3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting
3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting
3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting
3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting
3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting
Specifications
Brand Name :
HanWei
Model Number :
HW-20-60150
Certification :
CE
Place of Origin :
Shenzhen. China
MOQ :
1 Set
Price :
USD / Set
Payment Terms :
T/T
Supply Ability :
2000 Sets / year
Delivery Time :
10 working days
Packaging Details :
Export Plywood Packing
Handheld Laser Gun Materials :
Aluminium alloy & Stainless Steel
Handheld Laser Gun Weight :
0.7 Kg
Welding Laser Beam Size :
0-5mm Adjustable
Cleaning Laser Beam Size :
0-50mm Adjustable
Laser Power :
Up to 3000W for welding and 2000W for cleaning
Welding Materials :
Steel / Stainless Steel / Aluminium
Wire Feeding Device :
Standard type : 0.8&1.0&1.2&1.6mm wire
Double Route Wire Feeder :
Option ( Same time double route feeding )
Welding parameter storage :
30 kinds of different welding parameter save
Description

3-in-1 Laser Welding Machine with Portable Head for Welding / Cleaning and Cutting

3-in-1 Laser Welding Machine with Portable Head for Welding / Cleaning and Cutting Description:

The Handheld Single-Motor Tri-Function Device represents a significant breakthrough in the realm of portable multi-functional tools. Driven by a single yet powerful motor, this equipment combines three essential capabilities: welding, cutting, and cleaning, all housed within an ergonomically crafted and streamlined handheld housing.
For welding, it precisely controls current and voltage to generate a stable arc, enabling strong and accurate welds on various materials like steel, stainless steel, and aluminum. During cutting operations, a focused high-intensity beam penetrates materials of different thicknesses at adjustable speeds and depths, ensuring clean and efficient cuts. In cleaning mode, it draws in cleaning agents or water and transforms them into a powerful, adjustable high-pressure spray via a flexible nozzle, effectively removing rust, grime, and contaminants.
This apparatus demonstrates exceptional versatility, suitable for a wide range of environments—including workshops, construction sites, and industrial maintenance areas—delivering excellent performance across all three core functions.
.

3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting

3-in-1 Laser Welding Machine with Portable Head for Welding / Cleaning and Cutting Features:

  • Product Name: Fiber Laser 3-in-1 Machine
  • Handheld Laser Gun Weight: 0.7kg
  • Laser Power: Up to 3000W for welding and 2000W for cleaning
  • Welding Laser Beam Size: 0-5mm Adjustable
  • Cleaning Laser Beam Size: 0-50mm Adjustable
  • Standard Focus length: 60 and 150mm standard Focus length adjustable
  • Welding Materials: Steel / Stainless Steel / Aluminum
  • Laser Head Connection: QBH
  • Laser Beam Form: Line “一”
  • Cooling method: Water Cooling
  • Gas: Argon / Nitrogen

For metalworking, machinery repair, and surface pre-treatment tasks in workshops and manufacturing facilities, the Handheld Single-Motor Tri-Functional Apparatus is a top-tier option. With a peak power output of 3000W for welding and 2000W for cleaning, it effortlessly processes steel, stainless steel, and aluminum materials. Its laser beam features a linear configuration, connects via a QBH interface, and necessitates the use of argon or nitrogen gas.
Weighing merely 0.7 kilograms, this portable laser unit offers an adjustable standard focal length ranging from 60 to 150mm. Additionally, it enables precise adjustment of the laser beam diameter during both welding and cutting operations. The welding beam diameter can be modified within a 0 - 5mm range, while the cleaning beam diameter is variable from 0 to 50mm. To ensure efficient thermal management during operation, the device employs a water-cooling mechanism. This not only sustains consistent performance but also prolongs its operational lifespan.

3-in-1 Laser Welding Machine with Portable Head for Welding / Cleaning and Cutting Technical Parameters:

Product Name

Handheld Single Motor Three-in-One Machine

Laser Power

Up to 3000W for welding and 2000W for cleaning

Handheld Laser Gun Weight

0.7 KG

Cleaning Beam Form

Line " 一 "

Standard Focus length

60 and 150mm standard Focus length adjustable

Wire Feeding Device

Standard type : 0.8&1.0&1.2&1.6mm wire

Double Route Wire Feeder

Option (Same time double route feeding)

Welding Laser Beam Size

0-5mm Adjustable

Cleaning Laser Beam Size

0-50mm Adjustable

Fiber Connector

QBH

Adopt Laser Source

1064~1080nm Fiber laser source

Welding Parameter Save

30 kinds of different welding parameter save

3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting

3-in-1 Laser Welding Machine with Portable Head for Welding / Cleaning and Cutting Application Advantages:

The HanWei HW-20-60150 Handheld Single-Wobble Tri-Function Machine delivers exceptional application advantages. Its remarkable portability, stemming from a compact and lightweight design, makes it perfectly suited for use in confined spaces and mobile operations. This enhances operational flexibility without requiring complex machinery or a large workforce.
This device integrates welding, cutting, and cleaning capabilities. For welding, with a 3000W power output, it excels at joining steel, stainless steel, and aluminum. The welding beam, adjustable from 0 to 5mm, can meet diverse welding requirements. Regarding the cutting function, the laser beam can penetrate materials with adjustable cutting speed and depth. For cleaning, the 2000W-powered beam—adjustable from 0 to 50mm—offers high-efficiency cleaning across a wide range of surfaces, suitable for automotive, household, and industrial equipment maintenance.
It is energy-efficient and cost-effective. The single-motor configuration reduces energy consumption, streamlines workflows, and minimizes both time and energy costs. Its simple structure also lowers production and maintenance expenses. Additionally, it is user-friendly: no specialized training is required, making it accessible to a broad range of users while reducing errors and training-related costs.

3-in-1 Laser Welding Machine with Portable Head for Welding / Cleaning and Cutting Packing:

  • One Handheld Laser Head
  • Seven kinds of nozzles
  • A set of Connection Cables and Line
  • One 15v Power Supply
  • One Controller
  • One Touch Screen Monitor
  • One Focus Lens for cleaning
  • One Safety Switch Clip
  • Two Protective Lens
  • One Wire feeding device
  • One User Manual

3-in-1 Laser Welding Machine with Portable Laser Head for Welding / Cleaning and Cutting

Shen Zhen HanWei Laser Enterprise and Feature:

Shenzhen Hanwei Laser Equipment Co., Ltd. is dedicated to delivering superior welding technologies to global integrators. As a national high-tech and newly accredited specialized enterprise, it focuses on the R&D, manufacturing, and sales of a full industrial chain covering welding lasers, laser control systems, optical systems, and welding processes. The company’s product portfolio comprises nine major series of laser welding machines, including the AMB Spot Ring Spot Welding Machine, Blue Light Welding Machine, and their supporting components.

Guided by the principle of "R&D-driven, technology-backed, and service-supported," Hanwei Laser serves B2B clients with a team of experts possessing deep expertise in laser welding and related fields. Its products are widely applied across industries such as new energy batteries, automotive, electronics, and household appliances, demonstrating exceptional welding performance. Notably, the company has achieved world-leading innovations: the AMB Spot Ring Spot + Blue Light Composite Swing Welding Machine solves challenges in welding highly reflective materials, while models like the AMB Spot Ring Spot + Semiconductor Composite Welding Machine and Semiconductor + Single Lamp Single Rod 600W Composite Laser Welding Machine have efficiently addressed specific welding pain points in the power battery sector.
