Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning
Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning
Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning
Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning
Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning
Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning
Specifications
Brand Name :
HanWei
Model Number :
HW-20-60150
Certification :
CE
Place of Origin :
Shenzhen. China
MOQ :
1 Set
Price :
USD / Set
Payment Terms :
T/T
Supply Ability :
2000 Sets / year
Delivery Time :
10 working days
Packaging Details :
Export Plywood Packing
Handheld Laser Gun Weight :
0.7 Kg
Handheld Laser Gun Materials :
Aluminium alloy & Stainless Steel
Welding Materials :
Steel / Stainless Steel / Aluminium
Laser Power :
Up to 3000W for welding and 2000W for cleaning
Welding Laser Beam Size :
0-5mm Adjustable
Cleaning Laser Beam Size :
0-50mm Adjustable
Welding parameter storage :
30 kinds of different welding parameter save
Wire Feeding Device :
Standard type : 0.8&1.0&1.2&1.6mm wire
Double Route Wire Feeder :
Option ( Same time double route feeding )
Description

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Description:

The Handheld Single Motor 3-in-1 Device emerges as a remarkable innovation in the portable multi-purpose tool landscape. Driven by a solitary yet potent motor, this compact apparatus brings together the prowess of welding, the precision of cutting, and the thoroughness of cleansing, all encased within an ergonomically designed and sleek handheld casing.
In the welding domain, it astutely manages the electrical current and voltage to create a stable and reliable arc, thereby ensuring robust and exact welds on a variety of steel, stainless steel, and aluminum workpieces. When engaged in the cutting operation, a highly focused and intense beam slices through diverse thicknesses of materials with adjustable speed and depth settings, yielding clean and precise separations. For the cleaning function, it sucks in appropriate cleaning agents or water and transforms them into a powerful, adjustable high-pressure spray via a flexible nozzle, effectively eradicating rust, grease, and other impurities. This handheld three-in-one machine showcases unrivaled adaptability and finds utility in numerous settings such as bustling workshops, expansive construction sites, and demanding industrial maintenance tasks, consistently delivering top-notch performance in each of its welding, cutting, and cleaning capabilities.

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Features:

  • Product Name: Fiber Laser 3-in-1 Machine
  • Handheld Laser Gun Weight: 0.7kg
  • Welding Materials: Steel / Stainless Steel / Aluminum
  • Laser Head Connection: QBH
  • Laser Beam Form: Line “一”
  • Laser Power: Up to 3000W for welding and 2000W for cleaning
  • Welding Laser Beam Size: 0-5mm Adjustable
  • Cleaning Laser Beam Size: 0-50mm Adjustable
  • Standard Focus length: 60 and 150mm standard Focus length adjustable
  • Gas: Argon / Nitrogen
  • Cooling method: Water Cooling

The Handheld Single Motor 3-in-1 Appliance stands out as an outstanding alternative for metalworking, machinery restoration, and surface conditioning in workshops and manufacturing facilities. It employs a peak power of 3000W for welding and 2000W for cleaning, granting it the ability to manage steel, stainless steel, and aluminum substances. The laser emission assumes a linear shape and is connected through QBH, necessitating argon or nitrogen gas. The 0.7 - kilogram handheld laser gadget is equipped with an adjustable standard focal length spanning from 60 to 150mm. Additionally, it offers adjustable laser beam widths for welding and cutting, with the welding beam width adjustable from 0 to 5mm and the cleaning beam width from 0 to 50mm. This machine utilizes a Water Cooling mechanism to ensure efficient heat dispersion during operation, thereby maintaining its stable functionality and prolonging its service life.

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Technical Parameters:

Product Name

Handheld Single Motor 3-in-1 Machine

Adopt Laser Source

1064~1080nm Fiber laser source

Handheld Laser Gun Weight

0.7 KG

Laser Power

Up to 3000W for welding and 2000W for cleaning

Standard Focus length

60 and 150mm standard Focus length adjustable

Wire Feeding Device

Standard type : 0.8&1.0&1.2&1.6mm wire

Double Route Wire Feeder

Option (Same time double route feeding)

Cleaning Beam Form

Line " 一 "

Fiber Connector

QBH

Welding Laser Beam Size

0-5mm Adjustable

Cleaning Laser Beam Size

0-50mm Adjustable

Welding Parameter Input

Touch Screen Monitor

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Application Advantages:

The HanWei HW - 20 - 60150 Handheld Single Wobble Tri-functional Machine showcases remarkable application capabilities. Its highly favorable portability stems from its compact and lightweight design, making it ideal for confined spaces and mobile applications. This enhances operational flexibility without the need for complex machinery or a large workforce.
This apparatus combines the functions of welding, cutting, and cleaning. In terms of welding, with a power output of 3000W, it is highly competent in joining steel, stainless steel, and aluminum. The welding beam, adjustable within the range of 0 - 5mm, can meet diverse welding requirements. When it comes to the cutting function, the laser beam is capable of dividing materials with adjustable cutting speed and depth. In the cleaning function, with a power of 2000W, the 0 - 50mm adjustable beam is efficient in purifying a wide variety of surfaces and is applicable in automotive, household, and industrial equipment cleaning.
It is energy-efficient and cost-effective. The single-motor configuration saves energy, streamlines work processes, and reduces both time and energy consumption. Its simple structure leads to reductions in manufacturing and maintenance costs. It is also user-friendly, as it does not require specialized training, is accessible to a broad range of users, and helps to minimize errors and training-related expenses.

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Packing:

  • One Touch Screen Monitor
  • One Handheld Laser Head
  • One Controller
  • One 15v Power Supply
  • One Wire feeding device
  • One Focus Lens for cleaning
  • A set of Connection Cables and Line
  • Seven kinds of nozzles
  • Two Protective Lens
  • One Safety Switch Clip
  • One User Manual

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning

Shen Zhen HanWei Laser Enterprise and Feature:

Shenzhen Hanwei Laser Equipment Co., Ltd. is committed to endowing all global integrators with superior welding techniques. As a national high-tech and newly-designated specialized firm, it focuses on the R&D, production, and sales of the comprehensive industrial chain covering welding lasers, laser control systems, laser optical systems, and laser welding procedures. The company's product range comprises nine principal series of laser welding machines, such as the AMB Spot Ring Spot Welding Machine, Blue Light Welding Machine, along with their corresponding accessory products.

Hanwei Laser sticks to the business tenet of "highlighting R&D, underpinned by technology, and protected by service" to serve B-end customers. It possesses a proficient team with profound knowledge and rich experience in laser welding and related areas. The products have extensive applications in various industries like new energy batteries, automotive, electronics, and household appliances, exhibiting distinctive welding capabilities. Remarkably, the company has made significant technological advancements. The AMB Spot Ring Spot + Blue Light Composite Swing Welding Machine is a globally-leading innovation, resolving the difficulties in welding highly reflective materials. Other models like the AMB Spot Ring Spot + Semiconductor Composite Welding Machine and the Semiconductor + Single Lamp Single Rod 600W Composite Laser Welding Machine have also successfully addressed specific welding problems in the power battery field.
