Specifications
Brand Name :
GERUISI
Model Number :
GRS-MQ280
Place of Origin :
China
Payment Terms :
T/T, Western Union
Applicable Industries :
800～2000pc/Hour
die life :
≥ 30,000 times
Vertical burr :
≤15μm
horizontal burr :
≤20μm;
accuracy :
±0.1mm
Description
Semi-Automatic Pouch Cell Battery Electrode Die Cutter Cutting Punchin for laboratory Research
Product Description

* Infrared positioning device, accurate and convenient pole plate positioning die cutting;

* Easy and fast to replace the die;

* Long die life, normal use ≥ 30,000 times;

* No quality defects such as rough edges, powder drop, indentation;

* Between manual and automatic, high efficiency 800 ~ 2000 pieces/hour (1 ~ 8 pieces can be punched each time according to the chip size, the standard is 2 pieces);

* Adopts four guide column structure, sliding smoothly up and down with high precision;

* The equipment inlet has a safety protection light curtain, the operation is very safe;

* Exquisite appearance, sheet metal adopts three-dimensional geometric design, simple and beautiful;

* Easy to operate, safe and reliable, small size.

Specification

* Infrared positioning device, accurate and convenient pole plate positioning die cutting;

* Vertical burr ≤15μm, horizontal burr ≤20μm;

* Long die life, normal use ≥ 30,000 times;

* Maximum punching size: 280 * 180mm (can be customized according to customer requirements);

* Punching accuracy: ±0.1mm;

* Booster cylinder: 3T;

* Die cutting stroke: 150mm;

* Pneumatic hydraulic booster cylinder drive, punching force and punching speed can be adjusted;

* Production capacity: 800 ~ 2000EA/H (die cutting efficiency is slightly lower);

* With safety protection light curtain;

* Power supply: 220V/50Hz;

* Power: 100W;

* Compressed air: 0.5Mpa ~ 0.8Mpa;

* Dimensions: L580 * W455 * H900mm;

* Weight: 180kg.
