ASTM A 416 12.7mm ( 0.5 ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
ASTM A 416 12.7mm ( 0.5 ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
ASTM A 416 12.7mm ( 0.5 ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
ASTM A 416 12.7mm ( 0.5 ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
ASTM A 416 12.7mm ( 0.5 ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
ASTM A 416 12.7mm ( 0.5 ) PC Strand PC Steel Wire for Railway Sleeper 1860Mpa
Specifications
Brand Name :
Litong Global
Model Number :
LT-PC0426
Certification :
ISO9001-2008
Place of Origin :
Anhui,China
MOQ :
25tons
Price :
discuss
Supply Ability :
800tons/day
Packaging Details :
standard export packing in coil on 2 pallets
Material: :
82B wire rod
size: :
0.5",0.6"
Structure: :
1x7 and 1x19
Standard: :
ASTM A 416
Grade: :
1860MPA
Packing: :
2.5-3.2tons/coil
Description

ASTM A 416 12.7mm (0.5")PC Strand for Railway Sleeper 1860Mpa

Prestressed Concrete Steel Strand(PC Strand)

PC Strand is our most popular products in domestic and abroad market now.All of production lines for PC Strand,we introduce from MARIO FRIGERIO in Italy,Which is the first-class in the line in the World.upto 95% domestic market in Anhui Province,covered by us.We win most major projects through tenders from developed high-speed rail in China ,relying on our excellent quality.Litong’s PC Strand Annual output reached 100,000MT.

ASTM A 416 12.7mm ( 0.5

Product Range

Our PC Strand include:

.Size:9.53mm,12.7mm,15.24mm,17.8mm(9.5mm,12.7mm,15.2mm,15.7mm)

.Structure of Stand:1*7

.Main Production Standard:ASTM A 416,GB/T5224,BS5896,JIS G3536 etc.

.Application:High-speed rail.,Road bridge,buildings,foundations,stadiums,airport hangers, pre-cast segments, crane beams, anchorages and multi-storey industrial buildings etc.

ASTM A 416 12.7mm ( 0.5

Approvals,Certifications and Testing

.ISO9001-2008

. CANS-Certified

. China National Construction Steel Quality Supervision and Test Center Railway Construction Inspection Station

.SGS

.Vietnam Government ITST Test Report

ASTM A 416 12.7mm ( 0.5

Techical Parameters

7-Wire Uncoated Steel Strand for Prestressed Concrete as per ASTM A 416

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

 Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation
MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.53

+0.66,-0.15

 54.84 432 102.3 92.1

≥3.5

≤2.5
11.11 74.19 582 137.9 124.1
12.70 98.7 775 183.7 165.3
15.24 140.0 1102 260.7 234.6
17.80 190.0 1492 353.0 318.0
2000 12.70 +0.66,-0.15 98.7 775 197.4 177.7 ≥3.5 ≤2.5
15.24 140.0 1102 280.0 252.0

7-Wire Uncoated Steel Strand for Prestressed Concrete as per GB/T5224

Min.Breaking Strength

Nominal

Dia.

Dia.

Tolerance

Norminal

Steel

Area

 Nominal Weight

Min.

Breaking Load

Min.Load

at 1%Extension

Min.Elongation

Lo≥610mm

0.7 G.U.T.S

1000hNorminal Relaxation
MPA mm mm Mm2 Kg/Km KN KN % %
1860 9.50 +0.30,-0.15 54.8 432 102 86.6

≥3.5

≤2.5
11.10 74.2 580 138 117
12.70

+0.40,-0.20

 98.7 775 184 156
15.20 140 1101 259 220
15.70 150 1178 279 251
17.80 191 1500 353 318
1960 12.70 +0.40,-0.20 98.7 775 193 174 ≥3.5 ≤2.5
15.20 140 1101 274 247
