EU REACH Compliant Non-Asbestos Sealing Sheet - Eco-Friendly & Non-Toxic, Food Grade Available For Pharmaceutical/Food Machinery

This product page offers premium-grade sealing sheets compliant with strict EU REACH standards, available in thickness options from 0.5mm to 5.0mm. Optimal performance is achieved by selecting the minimum required thickness for your specific operational needs.

Technical Specifications:
Manufactured through advanced hot-roll compression technology, our sealing composites combine aramid fibers with NBR-enhanced synthetic rubber compounds. This engineered formulation delivers exceptional resistance to hydrocarbons, lubricants, and aqueous media, maintaining integrity when exposed to petroleum derivatives, natural gas, or water systems.

Performance Advantages:
• Multi-phase compatibility for dynamic industrial applications
• Certified asbestos-free composition (UKAS ISO9001 verified)
• Enhanced compression recovery with anti-delamination structure
• Cost-effective sealing solution with superior production yield
• Temperature-resistant variants (150℃/250℃/350℃ peak ratings)

Industrial Applications:
Specifically designed for precision sealing in:

• Power transmission systems (gearboxes/engine components)

• Pneumatic equipment (air compressors/pressure vessels)

• Pipeline networks and flange connections

• Marine engineering installations

• Food processing/pharmaceutical manufacturing equipment

Customizable Dimensions:
Standard sheet sizes include:
1500mm × (1500-4500mm)
1270mm × (1270-3810mm)
Thickness range: 0.5-5.0mm
Bespoke cutting services available for specialized requirements

Material Composition:
Advanced polymer matrix reinforced with:
• High-tensile aramid fibers
• Synthetic mineral composites
• Oil-resistant elastomer binders
• Thermal-stable additives

This next-generation sealing solution combines environmental compliance with industrial durability, meeting stringent requirements for both food contact applications and heavy-duty mechanical systems.

Physical Property:

Items			CSNXB150	CSNXB250	CSNXB350
Tensile Strength		Mpa	7.0	8.0	10.0
Compressibility		%	7-17
Recovery		≥%	40	45	50
Creep relaxation		≤%	40	35	30
Density		g/cm3	1.8±0.1
Flexibility at room temperature		Bend 180°C on the rod with diameter which is 12 times of nominal thickness of the sample, no crack.
Immersed into ASTM 3# at 150ºC for 5h	Tensile Strength	MPa≥	5.0	6.0	7.0
	Weight Increase	≤%	30
Immersed into ASTM B at21-30ºC for 5h	Thickness Increase	-	0-20
	Flexibility	-	No crack
Working Temperature	Max/Continuous	ºC	200/150	300/250	350/300
Working Pressure	Max/Continuous	MPa	2.0/1.0	4.0/2.0	5.0/3.0

Product Shows


Product Technical Details
As a general rule, Non-asbestos jointing gasket sheet is:
• Good for use with water
• Good for use with petrol
• Have good resistance to oil
