Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline
Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline
Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline
Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline
Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline
Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline
Specifications
Brand Name :
CLINGSEAL
Model Number :
CS1080T
Certification :
ISO,SGS
Place of Origin :
CHINA
MOQ :
500KGS
Price :
USD 2.15-3.0 PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100Tons per month
Delivery Time :
1-4 weeks
Packaging Details :
pallets or wooden case
Grade :
Industrial Grade
Type :
Flexible Sheet,Composite Sheet,Reinforced Sheet
Application :
Sealing for high temperature and high pressure environments
C content (%) :
99.9%,99%
Color :
Black
Material :
Graphite
Density :
1.3-1.5 g/cm³
Thickness :
0.5-5mm
Hardness :
80 Shore A
Product name :
Graphite sheet
Shape :
can be customized
Sample :
Availble
Width :
≤1500 mm
Recovery (%) :
≥35
Tensile Strength :
≥ 8MPa
Temperature Resistance :
Up to 650°C
Compressibility :
20-30%
Pressure Resistance :
Up to 200 bar
Reinforcement :
Metal mesh
Chemical Resistance :
Resistant to most chemicals
Recovery :
40-50%
Surface Finish :
Smooth
Description
Durable Reinforced Graphite Gasket Sheets for Oil and Gas Pipeline Applications​
In the high - stakes world of oil and gas pipeline operations, reliability is non - negotiable. Our durable reinforced graphite gasket sheets are engineered to be the ultimate sealing solution for your critical applications.​
Product Overview​
Our graphite gasket sheets are available in thicknesses spanning from 1.0 to 3mm. As a rule of thumb, selecting the thinnest material suitable for your specific oil and gas pipeline application not only optimizes performance but also cost - effectiveness. These sheets are constructed with two layers of pure, flexible graphite sheet, sandwiching a 0.2 - 0.25mm perforated metal insert. This unique structure provides enhanced strength and resilience, making them perfect for withstanding the rigors of oil and gas pipeline environments.​
Product Composition​
The perforated metal insert can be made from 0.2 - 0.25mm carbon steel, commonly known as tinplate. For more demanding corrosion - resistant requirements, options such as ss201, 304, and 316 are available. Additionally, you have the flexibility to choose graphite with carbon contents of 95%, 97%, 98%, or 99%, depending on your application's needs.

Oil Resistant Reinforced Graphite Gasket Sheet 99% For Oil And Gas Pipeline

Industrial Applications

Product Features

  • Exceptional Durability: Engineered to last, these gasket sheets offer outstanding adaptability and durability, ensuring they can withstand continuous use in oil and gas pipeline systems.
  • Superior Sealing Performance: With excellent sealing capabilities, our gasket sheets prevent leaks and ensure a tight fit. There is no risk of delamination, and they boast a high yield, making them a reliable choice for oil and gas applications.
  • Economical Solution: Despite their high - end performance, they are an economical option for sealing gaskets, whether it's for exhaust or manifold applications within the oil and gas industry.
  • High Oil - Resistance: Their remarkable oil - resistance property makes them an ideal choice for applications where exposure to various oils and hydrocarbons is inevitable.
  • Resistant to High Temperatures and Pressures: Capable of withstanding extreme conditions, these gasket sheets are suitable for high - temperature and high - pressure environments, which are common in oil and gas pipeline operations.

Product Applications

Specifically designed for oil and gas pipeline applications, these gasket sheets are perfect for oil sealing and general gasket use. They are also highly effective as cylinder head gaskets in the machinery associated with oil and gas transportation.

Product Sizes

  • Thickness: Our gasket sheets are available in thicknesses from 1.0 - 6.0mm. For thicker options, we offer the innovative 3 + 2 type, where the product section from top to bottom is arranged as Paper - Metal - Paper - Metal - Paper, utilizing multi - paper bonding technology for added strength.
  • Standard Sizes: We offer a range of standard sizes including 500500mm, 5001000mm, 5001500mm, 10001000mm, and 1000*1500mm. However, we understand that one size does not fit all. That's why we also provide custom sizing services to meet your unique requirements.
If you can't find the exact durable reinforced graphite gasket sheet for your oil and gas pipeline application or need a bespoke material, don't hesitate to reach out to us. Uncertain about which material is best for your specific use case? Consult our gasket material selector or our comprehensive guide to rubbers. Purchase your high - quality durable reinforced graphite gasket sheets for oil and gas pipeline applications from us today and experience unrivaled performance and reliability.



Physical Property:

Item Data
Tensile Strength (MPa,min.) ≥30
Compressibility (%,) 10-20
Recovery (%) ≥35
150ºC, At IRM 903# for 5hours Thickness Increase(%) ≤10
Weight Increase(%) ≤10
21ºC~30ºC, At B Fuel for 5hours Thickness Increase(%) ≤10
Weight Increase(%) ≤10
Thickness Deviation(mm) 0.05


Product Technical Details
As a general rule, graphite is:
• Good for use with steam
• Good ozone resistance
• Good with natural gas
